Collection: Gears - Spur - Standard - 32DP - 20 Degree

Gears (With Images)

Spur

Standard

32DP

14.5 Degree
20 Degree

Plastic

45 Products in this selection

This is a combined category of 20 Degree 32DP Standard Spur Gears.
Use the filters in the table below, or the category tree above to refine the selection. To order any item, simply click the part number for a full product page, then add to your cart.

Additional resources:
32DP Gear Racks

A more concise listing may be found on the Smallparts store at Gears - Spur - Standard - 32DP - 20 Degree. Smallparts promote the most popular MBA products.

Teeth	Pitch Circle Diameter (PD)	Bore (d)	Outside Diameter (OD)	Face Width (FW)	Type	Indicative Image
Teeth 12	Pitch Circle Diameter (PD) 9.53 mm _{(0.375 in.)}	Bore (d) 3.970 mm _{(0.156 in.)}	Outside Diameter (OD) 11.125 mm	Face Width (FW) 4.76 mm
Material: Acetal Hub Diameter (D1): 7.15 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G010B-12-D32-048-040-A-P Spur Gears - 12 tooth - 9.53x3.97 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.41 AUD Regular price Sale price $8.41 AUD Unit price per Each
Teeth	Pitch Circle Diameter (PD)	Bore (d)	Outside Diameter (OD)	Indicative Image
Teeth 12	Pitch Circle Diameter (PD) 9.53 mm _{(0.375 in.)}	Bore (d) 3.970 mm _{(0.156 in.)}	Outside Diameter (OD) 11.125 mm
Material: Acetal Face Width (FW): 4.76 mm Hub Diameter (D1): 7.15 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G010B-12-D32-048-040-A-P Spur Gears - 12 tooth - 9.53x3.97 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.41 AUD Regular price Sale price $8.41 AUD Unit price per Each View the product page first if you are unsure.
G010B-12-D32-048-040-A-P --- Spur Gears - 12 tooth - 9.53x3.97 mm - Acetal G010B-12-D32-048-040-A-P --- Spur Gears - 12 tooth - 9.53x3.97 mm - Acetal Regular price $8.41 AUD Regular price Sale price $8.41 AUD Unit price per Out of stock! Backorder Now
Teeth 16	Pitch Circle Diameter (PD) 12.70 mm _{(0.5 in.)}	Bore (d) 3.970 mm _{(0.156 in.)}	Outside Diameter (OD) 14.300 mm	Face Width (FW) 4.76 mm
Material: Acetal Hub Diameter (D1): 8.73 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G013B-16-D32-048-040-A-P Spur Gears - 16 tooth - 12.7x3.97 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.41 AUD Regular price Sale price $8.41 AUD Unit price per Each
Teeth 16	Pitch Circle Diameter (PD) 12.70 mm _{(0.5 in.)}	Bore (d) 3.970 mm _{(0.156 in.)}	Outside Diameter (OD) 14.300 mm
Material: Acetal Face Width (FW): 4.76 mm Hub Diameter (D1): 8.73 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G013B-16-D32-048-040-A-P Spur Gears - 16 tooth - 12.7x3.97 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.41 AUD Regular price Sale price $8.41 AUD Unit price per Each View the product page first if you are unsure.
G013B-16-D32-048-040-A-P --- Spur Gears - 16 tooth - 12.7x3.97 mm - Acetal G013B-16-D32-048-040-A-P --- Spur Gears - 16 tooth - 12.7x3.97 mm - Acetal Regular price $8.41 AUD Regular price Sale price $8.41 AUD Unit price per Out of stock! Backorder Now
Teeth 18	Pitch Circle Diameter (PD) 14.29 mm _{(0.563 in.)}	Bore (d) 3.970 mm _{(0.156 in.)}	Outside Diameter (OD) 15.900 mm	Face Width (FW) 4.76 mm
Material: Acetal Hub Diameter (D1): 8.73 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G014B-18-D32-048-040-A-P Spur Gears - 18 tooth - 14.29x3.97 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.41 AUD Regular price Sale price $8.41 AUD Unit price per Each
Teeth 18	Pitch Circle Diameter (PD) 14.29 mm _{(0.563 in.)}	Bore (d) 3.970 mm _{(0.156 in.)}	Outside Diameter (OD) 15.900 mm
Material: Acetal Face Width (FW): 4.76 mm Hub Diameter (D1): 8.73 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G014B-18-D32-048-040-A-P Spur Gears - 18 tooth - 14.29x3.97 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.41 AUD Regular price Sale price $8.41 AUD Unit price per Each View the product page first if you are unsure.
G014B-18-D32-048-040-A-P --- Spur Gears - 18 tooth - 14.29x3.97 mm - Acetal G014B-18-D32-048-040-A-P --- Spur Gears - 18 tooth - 14.29x3.97 mm - Acetal Regular price $8.41 AUD Regular price Sale price $8.41 AUD Unit price per Out of stock! Backorder Now
Teeth 20	Pitch Circle Diameter (PD) 15.88 mm _{(0.625 in.)}	Bore (d) 4.762 mm _{(0.187 in.)}	Outside Diameter (OD) 17.475 mm	Face Width (FW) 4.76 mm
Material: Acetal Hub Diameter (D1): 11.91 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G016B-20-D32-048-048-A-P Spur Gears - 20 tooth - 15.88x4.762 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.50 AUD Regular price Sale price $8.50 AUD Unit price per Each
Teeth 20	Pitch Circle Diameter (PD) 15.88 mm _{(0.625 in.)}	Bore (d) 4.762 mm _{(0.187 in.)}	Outside Diameter (OD) 17.475 mm
Material: Acetal Face Width (FW): 4.76 mm Hub Diameter (D1): 11.91 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G016B-20-D32-048-048-A-P Spur Gears - 20 tooth - 15.88x4.762 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.50 AUD Regular price Sale price $8.50 AUD Unit price per Each View the product page first if you are unsure.
G016B-20-D32-048-048-A-P --- Spur Gears - 20 tooth - 15.88x4.762 mm - Acetal G016B-20-D32-048-048-A-P --- Spur Gears - 20 tooth - 15.88x4.762 mm - Acetal Regular price $8.50 AUD Regular price Sale price $8.50 AUD Unit price per Out of stock! Backorder Now
Teeth 22	Pitch Circle Diameter (PD) 17.48 mm _{(0.688 in.)}	Bore (d) 4.762 mm _{(0.187 in.)}	Outside Diameter (OD) 19.075 mm	Face Width (FW) 4.76 mm
Material: Acetal Hub Diameter (D1): 12.70 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G017B-22-D32-048-048-A-P Spur Gears - 22 tooth - 17.48x4.762 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.50 AUD Regular price Sale price $8.50 AUD Unit price per Each
Teeth 22	Pitch Circle Diameter (PD) 17.48 mm _{(0.688 in.)}	Bore (d) 4.762 mm _{(0.187 in.)}	Outside Diameter (OD) 19.075 mm
Material: Acetal Face Width (FW): 4.76 mm Hub Diameter (D1): 12.70 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G017B-22-D32-048-048-A-P Spur Gears - 22 tooth - 17.48x4.762 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.50 AUD Regular price Sale price $8.50 AUD Unit price per Each View the product page first if you are unsure.
G017B-22-D32-048-048-A-P --- Spur Gears - 22 tooth - 17.48x4.762 mm - Acetal G017B-22-D32-048-048-A-P --- Spur Gears - 22 tooth - 17.48x4.762 mm - Acetal Regular price $8.50 AUD Regular price Sale price $8.50 AUD Unit price per Out of stock! Backorder Now
Teeth 22	Pitch Circle Diameter (PD) 17.48 mm _{(0.688 in.)}	Bore (d) 4.762 mm _{(0.187 in.)}	Outside Diameter (OD) 19.075 mm	Face Width (FW) 4.76 mm
Material: Acetal with Brass insert Hub Diameter (D1): 12.70 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G017B-22-D32-048-048-AB-G Spur Gears - 22 tooth - 17.48x4.762 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $15.14 AUD Regular price Sale price $15.14 AUD Unit price per Each
Teeth 22	Pitch Circle Diameter (PD) 17.48 mm _{(0.688 in.)}	Bore (d) 4.762 mm _{(0.187 in.)}	Outside Diameter (OD) 19.075 mm
Material: Acetal with Brass insert Face Width (FW): 4.76 mm Hub Diameter (D1): 12.70 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G017B-22-D32-048-048-AB-G Spur Gears - 22 tooth - 17.48x4.762 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $15.14 AUD Regular price Sale price $15.14 AUD Unit price per Each View the product page first if you are unsure.
G017B-22-D32-048-048-AB-G --- Spur Gears - 22 tooth - 17.48x4.762 mm - Acetal with Brass insert G017B-22-D32-048-048-AB-G --- Spur Gears - 22 tooth - 17.48x4.762 mm - Acetal with Brass insert Regular price $15.14 AUD Regular price Sale price $15.14 AUD Unit price per Out of stock! Backorder Now
Teeth 24	Pitch Circle Diameter (PD) 19.05 mm _{(0.75 in.)}	Bore (d) 4.762 mm _{(0.187 in.)}	Outside Diameter (OD) 20.650 mm	Face Width (FW) 4.76 mm
Material: Acetal Hub Diameter (D1): 12.70 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G019B-24-D32-048-048-A-P Spur Gears - 24 tooth - 19.05x4.762 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.50 AUD Regular price Sale price $8.50 AUD Unit price per Each
Teeth 24	Pitch Circle Diameter (PD) 19.05 mm _{(0.75 in.)}	Bore (d) 4.762 mm _{(0.187 in.)}	Outside Diameter (OD) 20.650 mm
Material: Acetal Face Width (FW): 4.76 mm Hub Diameter (D1): 12.70 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G019B-24-D32-048-048-A-P Spur Gears - 24 tooth - 19.05x4.762 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.50 AUD Regular price Sale price $8.50 AUD Unit price per Each View the product page first if you are unsure.
G019B-24-D32-048-048-A-P --- Spur Gears - 24 tooth - 19.05x4.762 mm - Acetal G019B-24-D32-048-048-A-P --- Spur Gears - 24 tooth - 19.05x4.762 mm - Acetal Regular price $8.50 AUD Regular price Sale price $8.50 AUD Unit price per Out of stock! Backorder Now
Teeth 24	Pitch Circle Diameter (PD) 19.05 mm _{(0.75 in.)}	Bore (d) 4.762 mm _{(0.187 in.)}	Outside Diameter (OD) 20.650 mm	Face Width (FW) 4.76 mm
Material: Acetal with Brass insert Hub Diameter (D1): 12.70 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G019B-24-D32-048-048-AB-G Spur Gears - 24 tooth - 19.05x4.762 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $15.50 AUD Regular price Sale price $15.50 AUD Unit price per Each
Teeth 24	Pitch Circle Diameter (PD) 19.05 mm _{(0.75 in.)}	Bore (d) 4.762 mm _{(0.187 in.)}	Outside Diameter (OD) 20.650 mm
Material: Acetal with Brass insert Face Width (FW): 4.76 mm Hub Diameter (D1): 12.70 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G019B-24-D32-048-048-AB-G Spur Gears - 24 tooth - 19.05x4.762 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $15.50 AUD Regular price Sale price $15.50 AUD Unit price per Each View the product page first if you are unsure.
G019B-24-D32-048-048-AB-G --- Spur Gears - 24 tooth - 19.05x4.762 mm - Acetal with Brass insert G019B-24-D32-048-048-AB-G --- Spur Gears - 24 tooth - 19.05x4.762 mm - Acetal with Brass insert Regular price $15.50 AUD Regular price Sale price $15.50 AUD Unit price per Out of stock! Backorder Now
Teeth 24	Pitch Circle Diameter (PD) 19.05 mm _{(0.75 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 20.650 mm	Face Width (FW) 4.76 mm
Material: Acetal Hub Diameter (D1): 9.53 mm Hub Projection (HL): 4.76 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G019B-24-D32-048-064-A-P Spur Gears - 24 tooth - 19.05x6.35 mm - Acetal 1 Available Immediately \| Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity Regular price $4.00 AUD Regular price ~~$7.60 AUD~~ Sale price $4.00 AUD Unit price per Each
Teeth 24	Pitch Circle Diameter (PD) 19.05 mm _{(0.75 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 20.650 mm
Material: Acetal Face Width (FW): 4.76 mm Hub Diameter (D1): 9.53 mm Hub Projection (HL): 4.76 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G019B-24-D32-048-064-A-P Spur Gears - 24 tooth - 19.05x6.35 mm - Acetal 1 Available Immediately \| Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity Regular price $4.00 AUD Regular price ~~$7.60 AUD~~ Sale price $4.00 AUD Unit price per Each
G019B-24-D32-048-064-A-P --- Spur Gears - 24 tooth - 19.05x6.35 mm - Acetal Sale G019B-24-D32-048-064-A-P --- Spur Gears - 24 tooth - 19.05x6.35 mm - Acetal Regular price $4.00 AUD Regular price ~~$7.60 AUD~~ Sale price $4.00 AUD Unit price per 1 Available Now Sale
Teeth 26	Pitch Circle Diameter (PD) 20.64 mm _{(0.813 in.)}	Bore (d) 4.762 mm _{(0.187 in.)}	Outside Diameter (OD) 22.250 mm	Face Width (FW) 4.76 mm
Material: Acetal Hub Diameter (D1): 14.29 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G021B-26-D32-048-048-A-P Spur Gears - 26 tooth - 20.64x4.762 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.59 AUD Regular price Sale price $8.59 AUD Unit price per Each
Teeth 26	Pitch Circle Diameter (PD) 20.64 mm _{(0.813 in.)}	Bore (d) 4.762 mm _{(0.187 in.)}	Outside Diameter (OD) 22.250 mm
Material: Acetal Face Width (FW): 4.76 mm Hub Diameter (D1): 14.29 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G021B-26-D32-048-048-A-P Spur Gears - 26 tooth - 20.64x4.762 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.59 AUD Regular price Sale price $8.59 AUD Unit price per Each View the product page first if you are unsure.
G021B-26-D32-048-048-A-P --- Spur Gears - 26 tooth - 20.64x4.762 mm - Acetal G021B-26-D32-048-048-A-P --- Spur Gears - 26 tooth - 20.64x4.762 mm - Acetal Regular price $8.59 AUD Regular price Sale price $8.59 AUD Unit price per Out of stock! Backorder Now
Teeth 26	Pitch Circle Diameter (PD) 20.64 mm _{(0.813 in.)}	Bore (d) 4.762 mm _{(0.187 in.)}	Outside Diameter (OD) 22.250 mm	Face Width (FW) 4.76 mm
Material: Acetal with Brass insert Hub Diameter (D1): 14.29 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G021B-26-D32-048-048-AB-G Spur Gears - 26 tooth - 20.64x4.762 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $16.05 AUD Regular price Sale price $16.05 AUD Unit price per Each
Teeth 26	Pitch Circle Diameter (PD) 20.64 mm _{(0.813 in.)}	Bore (d) 4.762 mm _{(0.187 in.)}	Outside Diameter (OD) 22.250 mm
Material: Acetal with Brass insert Face Width (FW): 4.76 mm Hub Diameter (D1): 14.29 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G021B-26-D32-048-048-AB-G Spur Gears - 26 tooth - 20.64x4.762 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $16.05 AUD Regular price Sale price $16.05 AUD Unit price per Each View the product page first if you are unsure.
G021B-26-D32-048-048-AB-G --- Spur Gears - 26 tooth - 20.64x4.762 mm - Acetal with Brass insert G021B-26-D32-048-048-AB-G --- Spur Gears - 26 tooth - 20.64x4.762 mm - Acetal with Brass insert Regular price $16.05 AUD Regular price Sale price $16.05 AUD Unit price per Out of stock! Backorder Now
Teeth 28	Pitch Circle Diameter (PD) 22.23 mm _{(0.875 in.)}	Bore (d) 4.762 mm _{(0.187 in.)}	Outside Diameter (OD) 23.825 mm	Face Width (FW) 4.76 mm
Material: Acetal with Brass insert Hub Diameter (D1): 12.70 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G022B-28-D32-048-048-AB-G Spur Gears - 28 tooth - 22.23x4.762 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $16.32 AUD Regular price Sale price $16.32 AUD Unit price per Each
Teeth 28	Pitch Circle Diameter (PD) 22.23 mm _{(0.875 in.)}	Bore (d) 4.762 mm _{(0.187 in.)}	Outside Diameter (OD) 23.825 mm
Material: Acetal with Brass insert Face Width (FW): 4.76 mm Hub Diameter (D1): 12.70 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G022B-28-D32-048-048-AB-G Spur Gears - 28 tooth - 22.23x4.762 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $16.32 AUD Regular price Sale price $16.32 AUD Unit price per Each View the product page first if you are unsure.
G022B-28-D32-048-048-AB-G --- Spur Gears - 28 tooth - 22.23x4.762 mm - Acetal with Brass insert G022B-28-D32-048-048-AB-G --- Spur Gears - 28 tooth - 22.23x4.762 mm - Acetal with Brass insert Regular price $16.32 AUD Regular price Sale price $16.32 AUD Unit price per Out of stock! Backorder Now
Teeth 28	Pitch Circle Diameter (PD) 22.23 mm _{(0.875 in.)}	Bore (d) 4.762 mm _{(0.187 in.)}	Outside Diameter (OD) 23.825 mm	Face Width (FW) 4.76 mm
Material: Acetal Hub Diameter (D1): 12.70 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G022B-28-D32-048-048-A-P Spur Gears - 28 tooth - 22.23x4.762 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.59 AUD Regular price Sale price $8.59 AUD Unit price per Each
Teeth 28	Pitch Circle Diameter (PD) 22.23 mm _{(0.875 in.)}	Bore (d) 4.762 mm _{(0.187 in.)}	Outside Diameter (OD) 23.825 mm
Material: Acetal Face Width (FW): 4.76 mm Hub Diameter (D1): 12.70 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G022B-28-D32-048-048-A-P Spur Gears - 28 tooth - 22.23x4.762 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.59 AUD Regular price Sale price $8.59 AUD Unit price per Each View the product page first if you are unsure.
G022B-28-D32-048-048-A-P --- Spur Gears - 28 tooth - 22.23x4.762 mm - Acetal G022B-28-D32-048-048-A-P --- Spur Gears - 28 tooth - 22.23x4.762 mm - Acetal Regular price $8.59 AUD Regular price Sale price $8.59 AUD Unit price per Out of stock! Backorder Now
Teeth 30	Pitch Circle Diameter (PD) 23.81 mm _{(0.937 in.)}	Bore (d) 4.762 mm _{(0.187 in.)}	Outside Diameter (OD) 25.425 mm	Face Width (FW) 4.76 mm
Material: Acetal with Brass insert Hub Diameter (D1): 14.29 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G024B-30-D32-048-048-AB-G Spur Gears - 30 tooth - 23.81x4.762 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $16.86 AUD Regular price Sale price $16.86 AUD Unit price per Each
Teeth 30	Pitch Circle Diameter (PD) 23.81 mm _{(0.937 in.)}	Bore (d) 4.762 mm _{(0.187 in.)}	Outside Diameter (OD) 25.425 mm
Material: Acetal with Brass insert Face Width (FW): 4.76 mm Hub Diameter (D1): 14.29 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G024B-30-D32-048-048-AB-G Spur Gears - 30 tooth - 23.81x4.762 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $16.86 AUD Regular price Sale price $16.86 AUD Unit price per Each View the product page first if you are unsure.
G024B-30-D32-048-048-AB-G --- Spur Gears - 30 tooth - 23.81x4.762 mm - Acetal with Brass insert G024B-30-D32-048-048-AB-G --- Spur Gears - 30 tooth - 23.81x4.762 mm - Acetal with Brass insert Regular price $16.86 AUD Regular price Sale price $16.86 AUD Unit price per Out of stock! Backorder Now
Teeth 30	Pitch Circle Diameter (PD) 23.81 mm _{(0.937 in.)}	Bore (d) 4.762 mm _{(0.187 in.)}	Outside Diameter (OD) 25.425 mm	Face Width (FW) 4.76 mm
Material: Acetal Hub Diameter (D1): 14.29 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G024B-30-D32-048-048-A-P Spur Gears - 30 tooth - 23.81x4.762 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.59 AUD Regular price Sale price $8.59 AUD Unit price per Each
Teeth 30	Pitch Circle Diameter (PD) 23.81 mm _{(0.937 in.)}	Bore (d) 4.762 mm _{(0.187 in.)}	Outside Diameter (OD) 25.425 mm
Material: Acetal Face Width (FW): 4.76 mm Hub Diameter (D1): 14.29 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G024B-30-D32-048-048-A-P Spur Gears - 30 tooth - 23.81x4.762 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.59 AUD Regular price Sale price $8.59 AUD Unit price per Each View the product page first if you are unsure.
G024B-30-D32-048-048-A-P --- Spur Gears - 30 tooth - 23.81x4.762 mm - Acetal G024B-30-D32-048-048-A-P --- Spur Gears - 30 tooth - 23.81x4.762 mm - Acetal Regular price $8.59 AUD Regular price Sale price $8.59 AUD Unit price per Out of stock! Backorder Now
Teeth 32	Pitch Circle Diameter (PD) 25.40 mm _{(1 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 27.000 mm	Face Width (FW) 4.76 mm
Material: Acetal with Brass insert Hub Diameter (D1): 15.88 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G025B-32-D32-048-064-AB-G Spur Gears - 32 tooth - 25.4x6.35 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $17.32 AUD Regular price Sale price $17.32 AUD Unit price per Each
Teeth 32	Pitch Circle Diameter (PD) 25.40 mm _{(1 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 27.000 mm
Material: Acetal with Brass insert Face Width (FW): 4.76 mm Hub Diameter (D1): 15.88 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G025B-32-D32-048-064-AB-G Spur Gears - 32 tooth - 25.4x6.35 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $17.32 AUD Regular price Sale price $17.32 AUD Unit price per Each View the product page first if you are unsure.
G025B-32-D32-048-064-AB-G --- Spur Gears - 32 tooth - 25.4x6.35 mm - Acetal with Brass insert G025B-32-D32-048-064-AB-G --- Spur Gears - 32 tooth - 25.4x6.35 mm - Acetal with Brass insert Regular price $17.32 AUD Regular price Sale price $17.32 AUD Unit price per Out of stock! Backorder Now
Teeth 32	Pitch Circle Diameter (PD) 25.40 mm _{(1 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 27.000 mm	Face Width (FW) 4.76 mm
Material: Acetal Hub Diameter (D1): 15.88 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G025B-32-D32-048-064-A-B Spur Gears - 32 tooth - 25.4x6.35 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.59 AUD Regular price Sale price $8.59 AUD Unit price per Each
Teeth 32	Pitch Circle Diameter (PD) 25.40 mm _{(1 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 27.000 mm
Material: Acetal Face Width (FW): 4.76 mm Hub Diameter (D1): 15.88 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G025B-32-D32-048-064-A-B Spur Gears - 32 tooth - 25.4x6.35 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.59 AUD Regular price Sale price $8.59 AUD Unit price per Each View the product page first if you are unsure.
G025B-32-D32-048-064-A-B --- Spur Gears - 32 tooth - 25.4x6.35 mm - Acetal G025B-32-D32-048-064-A-B --- Spur Gears - 32 tooth - 25.4x6.35 mm - Acetal Regular price $8.59 AUD Regular price Sale price $8.59 AUD Unit price per Out of stock! Backorder Now
Teeth 34	Pitch Circle Diameter (PD) 26.99 mm _{(1.063 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 28.600 mm	Face Width (FW) 4.76 mm
Material: Acetal Hub Diameter (D1): 15.48 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G027B-34-D32-048-064-A-P Spur Gears - 34 tooth - 26.99x6.35 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.68 AUD Regular price Sale price $8.68 AUD Unit price per Each
Teeth 34	Pitch Circle Diameter (PD) 26.99 mm _{(1.063 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 28.600 mm
Material: Acetal Face Width (FW): 4.76 mm Hub Diameter (D1): 15.48 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G027B-34-D32-048-064-A-P Spur Gears - 34 tooth - 26.99x6.35 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.68 AUD Regular price Sale price $8.68 AUD Unit price per Each View the product page first if you are unsure.
G027B-34-D32-048-064-A-P --- Spur Gears - 34 tooth - 26.99x6.35 mm - Acetal G027B-34-D32-048-064-A-P --- Spur Gears - 34 tooth - 26.99x6.35 mm - Acetal Regular price $8.68 AUD Regular price Sale price $8.68 AUD Unit price per Out of stock! Backorder Now
Teeth 34	Pitch Circle Diameter (PD) 26.99 mm _{(1.063 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 28.600 mm	Face Width (FW) 4.76 mm
Material: Acetal with Brass insert Hub Diameter (D1): 15.48 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G027B-34-D32-048-064-AB-G Spur Gears - 34 tooth - 26.99x6.35 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $17.86 AUD Regular price Sale price $17.86 AUD Unit price per Each
Teeth 34	Pitch Circle Diameter (PD) 26.99 mm _{(1.063 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 28.600 mm
Material: Acetal with Brass insert Face Width (FW): 4.76 mm Hub Diameter (D1): 15.48 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G027B-34-D32-048-064-AB-G Spur Gears - 34 tooth - 26.99x6.35 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $17.86 AUD Regular price Sale price $17.86 AUD Unit price per Each View the product page first if you are unsure.
G027B-34-D32-048-064-AB-G --- Spur Gears - 34 tooth - 26.99x6.35 mm - Acetal with Brass insert G027B-34-D32-048-064-AB-G --- Spur Gears - 34 tooth - 26.99x6.35 mm - Acetal with Brass insert Regular price $17.86 AUD Regular price Sale price $17.86 AUD Unit price per Out of stock! Backorder Now
Teeth 36	Pitch Circle Diameter (PD) 28.58 mm _{(1.125 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 30.175 mm	Face Width (FW) 4.76 mm
Material: Acetal Hub Diameter (D1): 15.48 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G029B-36-D32-048-064-A-B Spur Gears - 36 tooth - 28.58x6.35 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.68 AUD Regular price Sale price $8.68 AUD Unit price per Each
Teeth 36	Pitch Circle Diameter (PD) 28.58 mm _{(1.125 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 30.175 mm
Material: Acetal Face Width (FW): 4.76 mm Hub Diameter (D1): 15.48 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G029B-36-D32-048-064-A-B Spur Gears - 36 tooth - 28.58x6.35 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.68 AUD Regular price Sale price $8.68 AUD Unit price per Each View the product page first if you are unsure.
G029B-36-D32-048-064-A-B --- Spur Gears - 36 tooth - 28.58x6.35 mm - Acetal G029B-36-D32-048-064-A-B --- Spur Gears - 36 tooth - 28.58x6.35 mm - Acetal Regular price $8.68 AUD Regular price Sale price $8.68 AUD Unit price per Out of stock! Backorder Now
Teeth 36	Pitch Circle Diameter (PD) 28.58 mm _{(1.125 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 30.175 mm	Face Width (FW) 4.76 mm
Material: Acetal with Brass insert Hub Diameter (D1): 15.48 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G029B-36-D32-048-064-AB-G Spur Gears - 36 tooth - 28.58x6.35 mm - Acetal with Brass insert 1 Available Immediately \| Further orders can be expected around Tue, Jul 01, 2025 Regular price $18.05 AUD Regular price Sale price $18.05 AUD Unit price per Each
Teeth 36	Pitch Circle Diameter (PD) 28.58 mm _{(1.125 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 30.175 mm
Material: Acetal with Brass insert Face Width (FW): 4.76 mm Hub Diameter (D1): 15.48 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G029B-36-D32-048-064-AB-G Spur Gears - 36 tooth - 28.58x6.35 mm - Acetal with Brass insert 1 Available Immediately \| Further orders can be expected around Tue, Jul 01, 2025 Regular price $18.05 AUD Regular price Sale price $18.05 AUD Unit price per Each View the product page first if you are unsure.
G029B-36-D32-048-064-AB-G --- Spur Gears - 36 tooth - 28.58x6.35 mm - Acetal with Brass insert G029B-36-D32-048-064-AB-G --- Spur Gears - 36 tooth - 28.58x6.35 mm - Acetal with Brass insert Regular price $18.05 AUD Regular price Sale price $18.05 AUD Unit price per 1 Available Now
Teeth 38	Pitch Circle Diameter (PD) 30.18 mm _{(1.188 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 31.775 mm	Face Width (FW) 4.76 mm
Material: Acetal Hub Diameter (D1): 15.48 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G030B-38-D32-048-064-A-P Spur Gears - 38 tooth - 30.18x6.35 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.68 AUD Regular price Sale price $8.68 AUD Unit price per Each
Teeth 38	Pitch Circle Diameter (PD) 30.18 mm _{(1.188 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 31.775 mm
Material: Acetal Face Width (FW): 4.76 mm Hub Diameter (D1): 15.48 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G030B-38-D32-048-064-A-P Spur Gears - 38 tooth - 30.18x6.35 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.68 AUD Regular price Sale price $8.68 AUD Unit price per Each View the product page first if you are unsure.
G030B-38-D32-048-064-A-P --- Spur Gears - 38 tooth - 30.18x6.35 mm - Acetal G030B-38-D32-048-064-A-P --- Spur Gears - 38 tooth - 30.18x6.35 mm - Acetal Regular price $8.68 AUD Regular price Sale price $8.68 AUD Unit price per Out of stock! Backorder Now
Teeth 38	Pitch Circle Diameter (PD) 30.18 mm _{(1.188 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 31.775 mm	Face Width (FW) 4.76 mm
Material: Acetal with Brass insert Hub Diameter (D1): 15.48 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G030B-38-D32-048-064-AB-G Spur Gears - 38 tooth - 30.18x6.35 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $14.59 AUD Regular price Sale price $14.59 AUD Unit price per Each
Teeth 38	Pitch Circle Diameter (PD) 30.18 mm _{(1.188 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 31.775 mm
Material: Acetal with Brass insert Face Width (FW): 4.76 mm Hub Diameter (D1): 15.48 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G030B-38-D32-048-064-AB-G Spur Gears - 38 tooth - 30.18x6.35 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $14.59 AUD Regular price Sale price $14.59 AUD Unit price per Each View the product page first if you are unsure.
G030B-38-D32-048-064-AB-G --- Spur Gears - 38 tooth - 30.18x6.35 mm - Acetal with Brass insert G030B-38-D32-048-064-AB-G --- Spur Gears - 38 tooth - 30.18x6.35 mm - Acetal with Brass insert Regular price $14.59 AUD Regular price Sale price $14.59 AUD Unit price per Out of stock! Backorder Now
Teeth 40	Pitch Circle Diameter (PD) 31.75 mm _{(1.25 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 33.350 mm	Face Width (FW) 4.76 mm
Material: Acetal Hub Diameter (D1): 15.48 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G032B-40-D32-048-064-A-B Spur Gears - 40 tooth - 31.75x6.35 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.68 AUD Regular price Sale price $8.68 AUD Unit price per Each
Teeth 40	Pitch Circle Diameter (PD) 31.75 mm _{(1.25 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 33.350 mm
Material: Acetal Face Width (FW): 4.76 mm Hub Diameter (D1): 15.48 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G032B-40-D32-048-064-A-B Spur Gears - 40 tooth - 31.75x6.35 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.68 AUD Regular price Sale price $8.68 AUD Unit price per Each View the product page first if you are unsure.
G032B-40-D32-048-064-A-B --- Spur Gears - 40 tooth - 31.75x6.35 mm - Acetal G032B-40-D32-048-064-A-B --- Spur Gears - 40 tooth - 31.75x6.35 mm - Acetal Regular price $8.68 AUD Regular price Sale price $8.68 AUD Unit price per Out of stock! Backorder Now
