Collection: Gears - Spur - Standard - 32DP - 20 Degree

Gears (With Images)

Spur

Standard

32DP

14.5 Degree
20 Degree

Plastic

45 Products in this selection

This is a combined category of 20 Degree 32DP Standard Spur Gears.
Use the filters in the table below, or the category tree above to refine the selection. To order any item, simply click the part number for a full product page, then add to your cart.

Additional resources:
32DP Gear Racks

A more concise listing may be found on the Smallparts store at Gears - Spur - Standard - 32DP - 20 Degree. Smallparts promote the most popular MBA products.

Teeth	Pitch Circle Diameter (PD)	Bore (d)	Outside Diameter (OD)	Face Width (FW)	Type	Indicative Image
Teeth 40	Pitch Circle Diameter (PD) 31.75 mm _{(1.25 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 33.350 mm	Face Width (FW) 4.76 mm
Material: Acetal with Brass insert Hub Diameter (D1): 15.48 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G032B-40-D32-048-064-AB-G Spur Gears - 40 tooth - 31.75x6.35 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $19.23 AUD Regular price Sale price $19.23 AUD Unit price per Each
Teeth	Pitch Circle Diameter (PD)	Bore (d)	Outside Diameter (OD)	Indicative Image
Teeth 40	Pitch Circle Diameter (PD) 31.75 mm _{(1.25 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 33.350 mm
Material: Acetal with Brass insert Face Width (FW): 4.76 mm Hub Diameter (D1): 15.48 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G032B-40-D32-048-064-AB-G Spur Gears - 40 tooth - 31.75x6.35 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $19.23 AUD Regular price Sale price $19.23 AUD Unit price per Each View the product page first if you are unsure.
G032B-40-D32-048-064-AB-G --- Spur Gears - 40 tooth - 31.75x6.35 mm - Acetal with Brass insert G032B-40-D32-048-064-AB-G --- Spur Gears - 40 tooth - 31.75x6.35 mm - Acetal with Brass insert Regular price $19.23 AUD Regular price Sale price $19.23 AUD Unit price per Out of stock! Backorder Now
Teeth 42	Pitch Circle Diameter (PD) 33.34 mm _{(1.313 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 34.950 mm	Face Width (FW) 4.76 mm
Material: Acetal Hub Diameter (D1): 15.48 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G033B-42-D32-048-064-A-P Spur Gears - 42 tooth - 33.34x6.35 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.77 AUD Regular price Sale price $8.77 AUD Unit price per Each
Teeth 42	Pitch Circle Diameter (PD) 33.34 mm _{(1.313 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 34.950 mm
Material: Acetal Face Width (FW): 4.76 mm Hub Diameter (D1): 15.48 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G033B-42-D32-048-064-A-P Spur Gears - 42 tooth - 33.34x6.35 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.77 AUD Regular price Sale price $8.77 AUD Unit price per Each View the product page first if you are unsure.
G033B-42-D32-048-064-A-P --- Spur Gears - 42 tooth - 33.34x6.35 mm - Acetal G033B-42-D32-048-064-A-P --- Spur Gears - 42 tooth - 33.34x6.35 mm - Acetal Regular price $8.77 AUD Regular price Sale price $8.77 AUD Unit price per Out of stock! Backorder Now
Teeth 42	Pitch Circle Diameter (PD) 33.34 mm _{(1.313 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 34.950 mm	Face Width (FW) 4.76 mm
Material: Acetal with Brass insert Hub Diameter (D1): 15.48 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G033B-42-D32-048-064-AB-G Spur Gears - 42 tooth - 33.34x6.35 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $19.41 AUD Regular price Sale price $19.41 AUD Unit price per Each
Teeth 42	Pitch Circle Diameter (PD) 33.34 mm _{(1.313 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 34.950 mm
Material: Acetal with Brass insert Face Width (FW): 4.76 mm Hub Diameter (D1): 15.48 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G033B-42-D32-048-064-AB-G Spur Gears - 42 tooth - 33.34x6.35 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $19.41 AUD Regular price Sale price $19.41 AUD Unit price per Each View the product page first if you are unsure.
G033B-42-D32-048-064-AB-G --- Spur Gears - 42 tooth - 33.34x6.35 mm - Acetal with Brass insert G033B-42-D32-048-064-AB-G --- Spur Gears - 42 tooth - 33.34x6.35 mm - Acetal with Brass insert Regular price $19.41 AUD Regular price Sale price $19.41 AUD Unit price per Out of stock! Backorder Now
Teeth 44	Pitch Circle Diameter (PD) 34.93 mm _{(1.375 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 36.525 mm	Face Width (FW) 4.76 mm
Material: Acetal Hub Diameter (D1): 15.48 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G035B-44-D32-048-064-A-B Spur Gears - 44 tooth - 34.93x6.35 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.86 AUD Regular price Sale price $8.86 AUD Unit price per Each
Teeth 44	Pitch Circle Diameter (PD) 34.93 mm _{(1.375 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 36.525 mm
Material: Acetal Face Width (FW): 4.76 mm Hub Diameter (D1): 15.48 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G035B-44-D32-048-064-A-B Spur Gears - 44 tooth - 34.93x6.35 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.86 AUD Regular price Sale price $8.86 AUD Unit price per Each View the product page first if you are unsure.
G035B-44-D32-048-064-A-B --- Spur Gears - 44 tooth - 34.93x6.35 mm - Acetal G035B-44-D32-048-064-A-B --- Spur Gears - 44 tooth - 34.93x6.35 mm - Acetal Regular price $8.86 AUD Regular price Sale price $8.86 AUD Unit price per Out of stock! Backorder Now
Teeth 44	Pitch Circle Diameter (PD) 34.93 mm _{(1.375 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 36.525 mm	Face Width (FW) 4.76 mm
Material: Acetal with Brass insert Hub Diameter (D1): 15.48 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G035B-44-D32-048-064-AB-G Spur Gears - 44 tooth - 34.93x6.35 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $19.41 AUD Regular price Sale price $19.41 AUD Unit price per Each
Teeth 44	Pitch Circle Diameter (PD) 34.93 mm _{(1.375 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 36.525 mm
Material: Acetal with Brass insert Face Width (FW): 4.76 mm Hub Diameter (D1): 15.48 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G035B-44-D32-048-064-AB-G Spur Gears - 44 tooth - 34.93x6.35 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $19.41 AUD Regular price Sale price $19.41 AUD Unit price per Each View the product page first if you are unsure.
G035B-44-D32-048-064-AB-G --- Spur Gears - 44 tooth - 34.93x6.35 mm - Acetal with Brass insert G035B-44-D32-048-064-AB-G --- Spur Gears - 44 tooth - 34.93x6.35 mm - Acetal with Brass insert Regular price $19.41 AUD Regular price Sale price $19.41 AUD Unit price per Out of stock! Backorder Now
Teeth 48	Pitch Circle Diameter (PD) 38.10 mm _{(1.5 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 39.700 mm	Face Width (FW) 4.76 mm
Material: Acetal Hub Diameter (D1): 15.88 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G038B-48-D32-048-064-A-B Spur Gears - 48 tooth - 38.1x6.35 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.86 AUD Regular price Sale price $8.86 AUD Unit price per Each
Teeth 48	Pitch Circle Diameter (PD) 38.10 mm _{(1.5 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 39.700 mm
Material: Acetal Face Width (FW): 4.76 mm Hub Diameter (D1): 15.88 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G038B-48-D32-048-064-A-B Spur Gears - 48 tooth - 38.1x6.35 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.86 AUD Regular price Sale price $8.86 AUD Unit price per Each View the product page first if you are unsure.
G038B-48-D32-048-064-A-B --- Spur Gears - 48 tooth - 38.1x6.35 mm - Acetal G038B-48-D32-048-064-A-B --- Spur Gears - 48 tooth - 38.1x6.35 mm - Acetal Regular price $8.86 AUD Regular price Sale price $8.86 AUD Unit price per Out of stock! Backorder Now
Teeth 48	Pitch Circle Diameter (PD) 38.10 mm _{(1.5 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 39.700 mm	Face Width (FW) 4.76 mm
Material: Acetal Hub Diameter (D1): 11.10 mm Hub Projection (HL): 6.35 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G038B-48-D32-048-064-A-P Spur Gears - 48 tooth - 38.1x6.35 mm - Acetal 1 Available Immediately \| Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity Regular price $5.00 AUD Regular price ~~$9.50 AUD~~ Sale price $5.00 AUD Unit price per Each
Teeth 48	Pitch Circle Diameter (PD) 38.10 mm _{(1.5 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 39.700 mm
Material: Acetal Face Width (FW): 4.76 mm Hub Diameter (D1): 11.10 mm Hub Projection (HL): 6.35 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G038B-48-D32-048-064-A-P Spur Gears - 48 tooth - 38.1x6.35 mm - Acetal 1 Available Immediately \| Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity Regular price $5.00 AUD Regular price ~~$9.50 AUD~~ Sale price $5.00 AUD Unit price per Each
G038B-48-D32-048-064-A-P --- Spur Gears - 48 tooth - 38.1x6.35 mm - Acetal Sale G038B-48-D32-048-064-A-P --- Spur Gears - 48 tooth - 38.1x6.35 mm - Acetal Regular price $5.00 AUD Regular price ~~$9.50 AUD~~ Sale price $5.00 AUD Unit price per 1 Available Now Sale
Teeth 48	Pitch Circle Diameter (PD) 38.10 mm _{(1.5 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 39.700 mm	Face Width (FW) 4.76 mm
Material: Acetal with Brass insert Hub Diameter (D1): 15.88 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G038B-48-D32-048-064-AB-G Spur Gears - 48 tooth - 38.1x6.35 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $20.14 AUD Regular price Sale price $20.14 AUD Unit price per Each
Teeth 48	Pitch Circle Diameter (PD) 38.10 mm _{(1.5 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 39.700 mm
Material: Acetal with Brass insert Face Width (FW): 4.76 mm Hub Diameter (D1): 15.88 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G038B-48-D32-048-064-AB-G Spur Gears - 48 tooth - 38.1x6.35 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $20.14 AUD Regular price Sale price $20.14 AUD Unit price per Each View the product page first if you are unsure.
G038B-48-D32-048-064-AB-G --- Spur Gears - 48 tooth - 38.1x6.35 mm - Acetal with Brass insert G038B-48-D32-048-064-AB-G --- Spur Gears - 48 tooth - 38.1x6.35 mm - Acetal with Brass insert Regular price $20.14 AUD Regular price Sale price $20.14 AUD Unit price per Out of stock! Backorder Now
Teeth 52	Pitch Circle Diameter (PD) 41.28 mm _{(1.625 in.)}	Bore (d) 7.938 mm _{(0.313 in.)}	Outside Diameter (OD) 42.875 mm	Face Width (FW) 4.76 mm
Material: Acetal with Brass insert Hub Diameter (D1): 17.07 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G041B-52-D32-048-079-AB-G Spur Gears - 52 tooth - 41.28x7.938 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $20.68 AUD Regular price Sale price $20.68 AUD Unit price per Each
Teeth 52	Pitch Circle Diameter (PD) 41.28 mm _{(1.625 in.)}	Bore (d) 7.938 mm _{(0.313 in.)}	Outside Diameter (OD) 42.875 mm
Material: Acetal with Brass insert Face Width (FW): 4.76 mm Hub Diameter (D1): 17.07 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G041B-52-D32-048-079-AB-G Spur Gears - 52 tooth - 41.28x7.938 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $20.68 AUD Regular price Sale price $20.68 AUD Unit price per Each View the product page first if you are unsure.
G041B-52-D32-048-079-AB-G --- Spur Gears - 52 tooth - 41.28x7.938 mm - Acetal with Brass insert G041B-52-D32-048-079-AB-G --- Spur Gears - 52 tooth - 41.28x7.938 mm - Acetal with Brass insert Regular price $20.68 AUD Regular price Sale price $20.68 AUD Unit price per Out of stock! Backorder Now
Teeth 52	Pitch Circle Diameter (PD) 41.28 mm _{(1.625 in.)}	Bore (d) 7.938 mm _{(0.313 in.)}	Outside Diameter (OD) 42.875 mm	Face Width (FW) 4.76 mm
Material: Acetal Hub Diameter (D1): 17.07 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G041B-52-D32-048-079-A-P Spur Gears - 52 tooth - 41.28x7.938 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.86 AUD Regular price Sale price $8.86 AUD Unit price per Each
Teeth 52	Pitch Circle Diameter (PD) 41.28 mm _{(1.625 in.)}	Bore (d) 7.938 mm _{(0.313 in.)}	Outside Diameter (OD) 42.875 mm
Material: Acetal Face Width (FW): 4.76 mm Hub Diameter (D1): 17.07 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G041B-52-D32-048-079-A-P Spur Gears - 52 tooth - 41.28x7.938 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.86 AUD Regular price Sale price $8.86 AUD Unit price per Each View the product page first if you are unsure.
G041B-52-D32-048-079-A-P --- Spur Gears - 52 tooth - 41.28x7.938 mm - Acetal G041B-52-D32-048-079-A-P --- Spur Gears - 52 tooth - 41.28x7.938 mm - Acetal Regular price $8.86 AUD Regular price Sale price $8.86 AUD Unit price per Out of stock! Backorder Now
Teeth 56	Pitch Circle Diameter (PD) 44.45 mm _{(1.75 in.)}	Bore (d) 7.938 mm _{(0.313 in.)}	Outside Diameter (OD) 46.050 mm	Face Width (FW) 4.76 mm
Material: Acetal Hub Diameter (D1): 17.07 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G044B-56-D32-048-079-A-P Spur Gears - 56 tooth - 44.45x7.938 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.95 AUD Regular price Sale price $8.95 AUD Unit price per Each
Teeth 56	Pitch Circle Diameter (PD) 44.45 mm _{(1.75 in.)}	Bore (d) 7.938 mm _{(0.313 in.)}	Outside Diameter (OD) 46.050 mm
Material: Acetal Face Width (FW): 4.76 mm Hub Diameter (D1): 17.07 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G044B-56-D32-048-079-A-P Spur Gears - 56 tooth - 44.45x7.938 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $8.95 AUD Regular price Sale price $8.95 AUD Unit price per Each View the product page first if you are unsure.
G044B-56-D32-048-079-A-P --- Spur Gears - 56 tooth - 44.45x7.938 mm - Acetal G044B-56-D32-048-079-A-P --- Spur Gears - 56 tooth - 44.45x7.938 mm - Acetal Regular price $8.95 AUD Regular price Sale price $8.95 AUD Unit price per Out of stock! Backorder Now
Teeth 56	Pitch Circle Diameter (PD) 44.45 mm _{(1.75 in.)}	Bore (d) 7.938 mm _{(0.313 in.)}	Outside Diameter (OD) 46.050 mm	Face Width (FW) 4.76 mm
Material: Acetal with Brass insert Hub Diameter (D1): 17.07 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G044B-56-D32-048-079-AB-G Spur Gears - 56 tooth - 44.45x7.938 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $21.32 AUD Regular price Sale price $21.32 AUD Unit price per Each
Teeth 56	Pitch Circle Diameter (PD) 44.45 mm _{(1.75 in.)}	Bore (d) 7.938 mm _{(0.313 in.)}	Outside Diameter (OD) 46.050 mm
Material: Acetal with Brass insert Face Width (FW): 4.76 mm Hub Diameter (D1): 17.07 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G044B-56-D32-048-079-AB-G Spur Gears - 56 tooth - 44.45x7.938 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $21.32 AUD Regular price Sale price $21.32 AUD Unit price per Each View the product page first if you are unsure.
G044B-56-D32-048-079-AB-G --- Spur Gears - 56 tooth - 44.45x7.938 mm - Acetal with Brass insert G044B-56-D32-048-079-AB-G --- Spur Gears - 56 tooth - 44.45x7.938 mm - Acetal with Brass insert Regular price $21.32 AUD Regular price Sale price $21.32 AUD Unit price per Out of stock! Backorder Now
Teeth 60	Pitch Circle Diameter (PD) 47.63 mm _{(1.875 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 49.225 mm	Face Width (FW) 4.76 mm
Material: Acetal Hub Diameter (D1): 11.10 mm Hub Projection (HL): 6.35 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G048B-60-D32-048-064-A-P Spur Gears - 60 tooth - 47.63x6.35 mm - Acetal 1 Available Immediately \| Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity Regular price $5.00 AUD Regular price ~~$9.50 AUD~~ Sale price $5.00 AUD Unit price per Each
Teeth 60	Pitch Circle Diameter (PD) 47.63 mm _{(1.875 in.)}	Bore (d) 6.350 mm _{(0.25 in.)}	Outside Diameter (OD) 49.225 mm
Material: Acetal Face Width (FW): 4.76 mm Hub Diameter (D1): 11.10 mm Hub Projection (HL): 6.35 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G048B-60-D32-048-064-A-P Spur Gears - 60 tooth - 47.63x6.35 mm - Acetal 1 Available Immediately \| Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity Regular price $5.00 AUD Regular price ~~$9.50 AUD~~ Sale price $5.00 AUD Unit price per Each
G048B-60-D32-048-064-A-P --- Spur Gears - 60 tooth - 47.63x6.35 mm - Acetal Sale G048B-60-D32-048-064-A-P --- Spur Gears - 60 tooth - 47.63x6.35 mm - Acetal Regular price $5.00 AUD Regular price ~~$9.50 AUD~~ Sale price $5.00 AUD Unit price per 1 Available Now Sale
Teeth 64	Pitch Circle Diameter (PD) 50.80 mm _{(2 in.)}	Bore (d) 7.938 mm _{(0.313 in.)}	Outside Diameter (OD) 52.400 mm	Face Width (FW) 4.76 mm
Material: Acetal Hub Diameter (D1): 17.07 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G051B-64-D32-048-079-A-P Spur Gears - 64 tooth - 50.8x7.938 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $9.05 AUD Regular price Sale price $9.05 AUD Unit price per Each
Teeth 64	Pitch Circle Diameter (PD) 50.80 mm _{(2 in.)}	Bore (d) 7.938 mm _{(0.313 in.)}	Outside Diameter (OD) 52.400 mm
Material: Acetal Face Width (FW): 4.76 mm Hub Diameter (D1): 17.07 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G051B-64-D32-048-079-A-P Spur Gears - 64 tooth - 50.8x7.938 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $9.05 AUD Regular price Sale price $9.05 AUD Unit price per Each View the product page first if you are unsure.
G051B-64-D32-048-079-A-P --- Spur Gears - 64 tooth - 50.8x7.938 mm - Acetal G051B-64-D32-048-079-A-P --- Spur Gears - 64 tooth - 50.8x7.938 mm - Acetal Regular price $9.05 AUD Regular price Sale price $9.05 AUD Unit price per Out of stock! Backorder Now
Teeth 64	Pitch Circle Diameter (PD) 50.80 mm _{(2 in.)}	Bore (d) 7.938 mm _{(0.313 in.)}	Outside Diameter (OD) 52.400 mm	Face Width (FW) 4.76 mm
Material: Acetal with Brass insert Hub Diameter (D1): 17.07 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G051B-64-D32-048-079-AB-G Spur Gears - 64 tooth - 50.8x7.938 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $22.14 AUD Regular price Sale price $22.14 AUD Unit price per Each
Teeth 64	Pitch Circle Diameter (PD) 50.80 mm _{(2 in.)}	Bore (d) 7.938 mm _{(0.313 in.)}	Outside Diameter (OD) 52.400 mm
Material: Acetal with Brass insert Face Width (FW): 4.76 mm Hub Diameter (D1): 17.07 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G051B-64-D32-048-079-AB-G Spur Gears - 64 tooth - 50.8x7.938 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $22.14 AUD Regular price Sale price $22.14 AUD Unit price per Each View the product page first if you are unsure.
G051B-64-D32-048-079-AB-G --- Spur Gears - 64 tooth - 50.8x7.938 mm - Acetal with Brass insert G051B-64-D32-048-079-AB-G --- Spur Gears - 64 tooth - 50.8x7.938 mm - Acetal with Brass insert Regular price $22.14 AUD Regular price Sale price $22.14 AUD Unit price per Out of stock! Backorder Now
Teeth 72	Pitch Circle Diameter (PD) 57.15 mm _{(2.25 in.)}	Bore (d) 7.938 mm _{(0.313 in.)}	Outside Diameter (OD) 58.750 mm	Face Width (FW) 4.76 mm
Material: Acetal with Brass insert Hub Diameter (D1): 20.64 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G057B-72-D32-048-079-AB-G Spur Gears - 72 tooth - 57.15x7.938 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $23.59 AUD Regular price Sale price $23.59 AUD Unit price per Each
Teeth 72	Pitch Circle Diameter (PD) 57.15 mm _{(2.25 in.)}	Bore (d) 7.938 mm _{(0.313 in.)}	Outside Diameter (OD) 58.750 mm
Material: Acetal with Brass insert Face Width (FW): 4.76 mm Hub Diameter (D1): 20.64 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G057B-72-D32-048-079-AB-G Spur Gears - 72 tooth - 57.15x7.938 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $23.59 AUD Regular price Sale price $23.59 AUD Unit price per Each View the product page first if you are unsure.
G057B-72-D32-048-079-AB-G --- Spur Gears - 72 tooth - 57.15x7.938 mm - Acetal with Brass insert G057B-72-D32-048-079-AB-G --- Spur Gears - 72 tooth - 57.15x7.938 mm - Acetal with Brass insert Regular price $23.59 AUD Regular price Sale price $23.59 AUD Unit price per Out of stock! Backorder Now
Teeth 72	Pitch Circle Diameter (PD) 57.15 mm _{(2.25 in.)}	Bore (d) 7.938 mm _{(0.313 in.)}	Outside Diameter (OD) 58.750 mm	Face Width (FW) 4.76 mm
Material: Acetal Hub Diameter (D1): 20.64 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G057B-72-D32-048-079-A-P Spur Gears - 72 tooth - 57.15x7.938 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $9.14 AUD Regular price Sale price $9.14 AUD Unit price per Each
Teeth 72	Pitch Circle Diameter (PD) 57.15 mm _{(2.25 in.)}	Bore (d) 7.938 mm _{(0.313 in.)}	Outside Diameter (OD) 58.750 mm
Material: Acetal Face Width (FW): 4.76 mm Hub Diameter (D1): 20.64 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G057B-72-D32-048-079-A-P Spur Gears - 72 tooth - 57.15x7.938 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $9.14 AUD Regular price Sale price $9.14 AUD Unit price per Each View the product page first if you are unsure.
G057B-72-D32-048-079-A-P --- Spur Gears - 72 tooth - 57.15x7.938 mm - Acetal G057B-72-D32-048-079-A-P --- Spur Gears - 72 tooth - 57.15x7.938 mm - Acetal Regular price $9.14 AUD Regular price Sale price $9.14 AUD Unit price per Out of stock! Backorder Now
Teeth 80	Pitch Circle Diameter (PD) 63.50 mm _{(2.5 in.)}	Bore (d) 7.938 mm _{(0.313 in.)}	Outside Diameter (OD) 65.100 mm	Face Width (FW) 4.76 mm
Material: Acetal Hub Diameter (D1): 20.64 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G064B-80-D32-048-079-A-P Spur Gears - 80 tooth - 63.5x7.938 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $9.14 AUD Regular price Sale price $9.14 AUD Unit price per Each
Teeth 80	Pitch Circle Diameter (PD) 63.50 mm _{(2.5 in.)}	Bore (d) 7.938 mm _{(0.313 in.)}	Outside Diameter (OD) 65.100 mm
Material: Acetal Face Width (FW): 4.76 mm Hub Diameter (D1): 20.64 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G064B-80-D32-048-079-A-P Spur Gears - 80 tooth - 63.5x7.938 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $9.14 AUD Regular price Sale price $9.14 AUD Unit price per Each View the product page first if you are unsure.
G064B-80-D32-048-079-A-P --- Spur Gears - 80 tooth - 63.5x7.938 mm - Acetal G064B-80-D32-048-079-A-P --- Spur Gears - 80 tooth - 63.5x7.938 mm - Acetal Regular price $9.14 AUD Regular price Sale price $9.14 AUD Unit price per Out of stock! Backorder Now
Teeth 80	Pitch Circle Diameter (PD) 63.50 mm _{(2.5 in.)}	Bore (d) 7.938 mm _{(0.313 in.)}	Outside Diameter (OD) 65.100 mm	Face Width (FW) 4.76 mm
Material: Acetal with Brass insert Hub Diameter (D1): 20.64 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G064B-80-D32-048-079-AB-G Spur Gears - 80 tooth - 63.5x7.938 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $24.32 AUD Regular price Sale price $24.32 AUD Unit price per Each
Teeth 80	Pitch Circle Diameter (PD) 63.50 mm _{(2.5 in.)}	Bore (d) 7.938 mm _{(0.313 in.)}	Outside Diameter (OD) 65.100 mm
Material: Acetal with Brass insert Face Width (FW): 4.76 mm Hub Diameter (D1): 20.64 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G064B-80-D32-048-079-AB-G Spur Gears - 80 tooth - 63.5x7.938 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $24.32 AUD Regular price Sale price $24.32 AUD Unit price per Each View the product page first if you are unsure.
G064B-80-D32-048-079-AB-G --- Spur Gears - 80 tooth - 63.5x7.938 mm - Acetal with Brass insert G064B-80-D32-048-079-AB-G --- Spur Gears - 80 tooth - 63.5x7.938 mm - Acetal with Brass insert Regular price $24.32 AUD Regular price Sale price $24.32 AUD Unit price per Out of stock! Backorder Now
Teeth 96	Pitch Circle Diameter (PD) 76.20 mm _{(3 in.)}	Bore (d) 7.938 mm _{(0.313 in.)}	Outside Diameter (OD) 77.800 mm	Face Width (FW) 4.76 mm
Material: Acetal Hub Diameter (D1): 20.64 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G076B-96-D32-048-079-A-P Spur Gears - 96 tooth - 76.2x7.938 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $9.41 AUD Regular price Sale price $9.41 AUD Unit price per Each
Teeth 96	Pitch Circle Diameter (PD) 76.20 mm _{(3 in.)}	Bore (d) 7.938 mm _{(0.313 in.)}	Outside Diameter (OD) 77.800 mm
Material: Acetal Face Width (FW): 4.76 mm Hub Diameter (D1): 20.64 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - No Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G076B-96-D32-048-079-A-P Spur Gears - 96 tooth - 76.2x7.938 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $9.41 AUD Regular price Sale price $9.41 AUD Unit price per Each View the product page first if you are unsure.
G076B-96-D32-048-079-A-P --- Spur Gears - 96 tooth - 76.2x7.938 mm - Acetal G076B-96-D32-048-079-A-P --- Spur Gears - 96 tooth - 76.2x7.938 mm - Acetal Regular price $9.41 AUD Regular price Sale price $9.41 AUD Unit price per Out of stock! Backorder Now
Teeth 96	Pitch Circle Diameter (PD) 76.20 mm _{(3 in.)}	Bore (d) 7.938 mm _{(0.313 in.)}	Outside Diameter (OD) 77.800 mm	Face Width (FW) 4.76 mm
Material: Acetal with Brass insert Hub Diameter (D1): 20.64 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G076B-96-D32-048-079-AB-G Spur Gears - 96 tooth - 76.2x7.938 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $27.14 AUD Regular price Sale price $27.14 AUD Unit price per Each
Teeth 96	Pitch Circle Diameter (PD) 76.20 mm _{(3 in.)}	Bore (d) 7.938 mm _{(0.313 in.)}	Outside Diameter (OD) 77.800 mm
Material: Acetal with Brass insert Face Width (FW): 4.76 mm Hub Diameter (D1): 20.64 mm Hub Projection (HL): 7.94 mm Locking Method: Pin Hub - Set Screw Category: Gears - Spur - Standard - 32DP - 20 Degree - Plastic
Part Number: G076B-96-D32-048-079-AB-G Spur Gears - 96 tooth - 76.2x7.938 mm - Acetal with Brass insert Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 01, 2025 Regular price $27.14 AUD Regular price Sale price $27.14 AUD Unit price per Each View the product page first if you are unsure.
G076B-96-D32-048-079-AB-G --- Spur Gears - 96 tooth - 76.2x7.938 mm - Acetal with Brass insert G076B-96-D32-048-079-AB-G --- Spur Gears - 96 tooth - 76.2x7.938 mm - Acetal with Brass insert Regular price $27.14 AUD Regular price Sale price $27.14 AUD Unit price per Out of stock! Backorder Now
