Collection: R Clips - Double Coil

R Clips (With Images)

Double Coil

Steel

8 Products in this selection

This is a combined category of Double Coil R Clips.
Use the filters in the table below, or the category tree above to refine the selection. To order any item, simply click the part number for a full product page, then add to your cart.

Additional resources:
Split Pins

A more concise listing may be found on the Smallparts store at R Clips - Double Coil. Smallparts promote the most popular MBA products.

Wire Thickness (d)	Length (L)	Material	Drill Hole Size	Inside Eye Diameter (D)	Shaft Size Range
Wire Thickness (d) 2.00 mm _{(0.079 in.)}	Length (L) 57.0 mm _{(2.244 in.)}	Material Zinc Plated	Drill Hole Size 2.50 mm	Inside Eye Diameter (D) 10.00 mm	Shaft Size Range 8.00 to 14.00 mm
Material: Spring Steel Zinc Plated Approx. Bridge Length (D1): 19 mm Category: R Clips - Double Coil - Steel
Part Number: RCL-020-057-ZD (5 Pcs) Double Coil R Clips - 2x57 mm - Zinc Plated 555 units (2775 pcs) Available Immediately \| Further orders can be expected around Tue, Jul 22, 2025 Regular price $3.23 AUD Regular price Sale price $3.23 AUD Unit price per Per 5
Wire Thickness (d)	Length (L)	Material	Drill Hole Size	Indicative Image
Wire Thickness (d) 2.00 mm _{(0.079 in.)}	Length (L) 57.0 mm _{(2.244 in.)}	Material Zinc Plated	Drill Hole Size 2.50 mm
Material: Spring Steel Zinc Plated Inside Eye Diameter (D): 10.00 mm Shaft Size Range: 8.00 to 14.00 mm Approx. Bridge Length (D1): 19 mm Category: R Clips - Double Coil - Steel
Part Number: RCL-020-057-ZD (5 Pcs) Double Coil R Clips - 2x57 mm - Zinc Plated 555 units (2775 pcs) Available Immediately \| Further orders can be expected around Tue, Jul 22, 2025 Regular price $3.23 AUD Regular price Sale price $3.23 AUD Unit price per Per 5 View the product page first if you are unsure.
RCL-020-057-ZD (5 Pcs) --- Double Coil R Clips - 2x57 mm - Zinc Plated RCL-020-057-ZD (5 Pcs) --- Double Coil R Clips - 2x57 mm - Zinc Plated Regular price $3.23 AUD Regular price Sale price $3.23 AUD Unit price per 555 Available Now
Wire Thickness (d) 2.50 mm _{(0.098 in.)}	Length (L) 49.0 mm _{(1.929 in.)}	Material Zinc Plated	Drill Hole Size 2.50 mm	Inside Eye Diameter (D) 10.00 mm	Shaft Size Range 8.00 to 14.00 mm
Material: Spring Steel Zinc Plated Approx. Bridge Length (D1): 17 mm Category: R Clips - Double Coil - Steel
Part Number: RCL-025-049-ZD (100 Pcs) Double Coil R Clips - 2.5x49 mm - Zinc Plated Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 22, 2025 Regular price $276.23 AUD Regular price Sale price $276.23 AUD Unit price per Per 100
Wire Thickness (d) 2.50 mm _{(0.098 in.)}	Length (L) 49.0 mm _{(1.929 in.)}	Material Zinc Plated	Drill Hole Size 2.50 mm
Material: Spring Steel Zinc Plated Inside Eye Diameter (D): 10.00 mm Shaft Size Range: 8.00 to 14.00 mm Approx. Bridge Length (D1): 17 mm Category: R Clips - Double Coil - Steel
Part Number: RCL-025-049-ZD (100 Pcs) Double Coil R Clips - 2.5x49 mm - Zinc Plated Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 22, 2025 Regular price $276.23 AUD Regular price Sale price $276.23 AUD Unit price per Per 100 View the product page first if you are unsure.
RCL-025-049-ZD (100 Pcs) --- Double Coil R Clips - 2.5x49 mm - Zinc Plated RCL-025-049-ZD (100 Pcs) --- Double Coil R Clips - 2.5x49 mm - Zinc Plated Regular price $276.23 AUD Regular price Sale price $276.23 AUD Unit price per Out of stock! Backorder Now
Wire Thickness (d) 3.00 mm _{(0.118 in.)}	Length (L) 73.0 mm _{(2.874 in.)}	Material Zinc Plated	Drill Hole Size 3.50 mm	Inside Eye Diameter (D) 16.00 mm	Shaft Size Range 14.00 to 20.00 mm
Material: Spring Steel Zinc Plated Approx. Bridge Length (D1): 26 mm Category: R Clips - Double Coil - Steel
Part Number: RCL-030-073-ZD (2 Pcs) Double Coil R Clips - 3x73 mm - Zinc Plated 70 units (140 pcs) Available Immediately \| Further orders can be expected around Tue, Jul 22, 2025 Regular price $8.95 AUD Regular price Sale price $8.95 AUD Unit price per Per 2
Wire Thickness (d) 3.00 mm _{(0.118 in.)}	Length (L) 73.0 mm _{(2.874 in.)}	Material Zinc Plated	Drill Hole Size 3.50 mm
Material: Spring Steel Zinc Plated Inside Eye Diameter (D): 16.00 mm Shaft Size Range: 14.00 to 20.00 mm Approx. Bridge Length (D1): 26 mm Category: R Clips - Double Coil - Steel
Part Number: RCL-030-073-ZD (2 Pcs) Double Coil R Clips - 3x73 mm - Zinc Plated 70 units (140 pcs) Available Immediately \| Further orders can be expected around Tue, Jul 22, 2025 Regular price $8.95 AUD Regular price Sale price $8.95 AUD Unit price per Per 2 View the product page first if you are unsure.
RCL-030-073-ZD (2 Pcs) --- Double Coil R Clips - 3x73 mm - Zinc Plated RCL-030-073-ZD (2 Pcs) --- Double Coil R Clips - 3x73 mm - Zinc Plated Regular price $8.95 AUD Regular price Sale price $8.95 AUD Unit price per 70 Available Now
Wire Thickness (d) 4.00 mm _{(0.157 in.)}	Length (L) 94.0 mm _{(3.701 in.)}	Material Zinc Plated	Drill Hole Size 4.50 mm	Inside Eye Diameter (D) 23.00 mm	Shaft Size Range 17.00 to 24.00 mm
Material: Spring Steel Zinc Plated Approx. Bridge Length (D1): 30 mm Category: R Clips - Double Coil - Steel
Part Number: RCL-040-094-ZD Double Coil R Clips - 4x94 mm - Zinc Plated 243 Available Immediately \| Further orders can be expected around Tue, Jul 22, 2025 Regular price $5.68 AUD Regular price Sale price $5.68 AUD Unit price per Each
Wire Thickness (d) 4.00 mm _{(0.157 in.)}	Length (L) 94.0 mm _{(3.701 in.)}	Material Zinc Plated	Drill Hole Size 4.50 mm
Material: Spring Steel Zinc Plated Inside Eye Diameter (D): 23.00 mm Shaft Size Range: 17.00 to 24.00 mm Approx. Bridge Length (D1): 30 mm Category: R Clips - Double Coil - Steel
Part Number: RCL-040-094-ZD Double Coil R Clips - 4x94 mm - Zinc Plated 243 Available Immediately \| Further orders can be expected around Tue, Jul 22, 2025 Regular price $5.68 AUD Regular price Sale price $5.68 AUD Unit price per Each View the product page first if you are unsure.
RCL-040-094-ZD --- Double Coil R Clips - 4x94 mm - Zinc Plated RCL-040-094-ZD --- Double Coil R Clips - 4x94 mm - Zinc Plated Regular price $5.68 AUD Regular price Sale price $5.68 AUD Unit price per 243 Available Now
Wire Thickness (d) 5.00 mm _{(0.197 in.)}	Length (L) 110.0 mm _{(4.331 in.)}	Material Zinc Plated	Drill Hole Size 5.50 mm	Inside Eye Diameter (D) 26.00 mm	Shaft Size Range 18.00 to 30.00 mm
Material: Spring Steel Zinc Plated Approx. Bridge Length (D1): 40 mm Category: R Clips - Double Coil - Steel
Part Number: RCL-050-110-ZD (100 Pcs) Double Coil R Clips - 5x110 mm - Zinc Plated Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 22, 2025 Regular price $726.32 AUD Regular price Sale price $726.32 AUD Unit price per Per 100
Wire Thickness (d) 5.00 mm _{(0.197 in.)}	Length (L) 110.0 mm _{(4.331 in.)}	Material Zinc Plated	Drill Hole Size 5.50 mm
Material: Spring Steel Zinc Plated Inside Eye Diameter (D): 26.00 mm Shaft Size Range: 18.00 to 30.00 mm Approx. Bridge Length (D1): 40 mm Category: R Clips - Double Coil - Steel
Part Number: RCL-050-110-ZD (100 Pcs) Double Coil R Clips - 5x110 mm - Zinc Plated Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 22, 2025 Regular price $726.32 AUD Regular price Sale price $726.32 AUD Unit price per Per 100 View the product page first if you are unsure.
RCL-050-110-ZD (100 Pcs) --- Double Coil R Clips - 5x110 mm - Zinc Plated RCL-050-110-ZD (100 Pcs) --- Double Coil R Clips - 5x110 mm - Zinc Plated Regular price $726.32 AUD Regular price Sale price $726.32 AUD Unit price per Out of stock! Backorder Now
Wire Thickness (d) 6.00 mm _{(0.236 in.)}	Length (L) 141.0 mm _{(5.551 in.)}	Material Zinc Plated	Drill Hole Size 6.50 mm	Inside Eye Diameter (D) 30.00 mm	Shaft Size Range 24.00 to 36.00 mm
Material: Spring Steel Zinc Plated Approx. Bridge Length (D1): 44 mm Category: R Clips - Double Coil - Steel
Part Number: RCL-060-141-ZD Double Coil R Clips - 6x141 mm - Zinc Plated 167 Available Immediately \| Further orders can be expected around Tue, Jul 22, 2025 Regular price $3.05 AUD Regular price ~~$3.65 AUD~~ Sale price $3.05 AUD Unit price per Each
Wire Thickness (d) 6.00 mm _{(0.236 in.)}	Length (L) 141.0 mm _{(5.551 in.)}	Material Zinc Plated	Drill Hole Size 6.50 mm
Material: Spring Steel Zinc Plated Inside Eye Diameter (D): 30.00 mm Shaft Size Range: 24.00 to 36.00 mm Approx. Bridge Length (D1): 44 mm Category: R Clips - Double Coil - Steel
Part Number: RCL-060-141-ZD Double Coil R Clips - 6x141 mm - Zinc Plated 167 Available Immediately \| Further orders can be expected around Tue, Jul 22, 2025 Regular price $3.05 AUD Regular price ~~$3.65 AUD~~ Sale price $3.05 AUD Unit price per Each View the product page first if you are unsure.
RCL-060-141-ZD --- Double Coil R Clips - 6x141 mm - Zinc Plated Sale RCL-060-141-ZD --- Double Coil R Clips - 6x141 mm - Zinc Plated Regular price $3.05 AUD Regular price ~~$3.65 AUD~~ Sale price $3.05 AUD Unit price per 167 Available Now Sale
Wire Thickness (d) 7.00 mm _{(0.276 in.)}	Length (L) 152.0 mm _{(5.984 in.)}	Material Zinc Plated	Drill Hole Size 8.00 mm	Inside Eye Diameter (D) 30.00 mm	Shaft Size Range 26.00 to 40.00 mm
Material: Spring Steel Zinc Plated Approx. Bridge Length (D1): 48 mm Category: R Clips - Double Coil - Steel
Part Number: RCL-070-152-ZD Double Coil R Clips - 7x152 mm - Zinc Plated 18 Available Immediately \| Further orders can be expected around Tue, Jul 22, 2025 Regular price $5.23 AUD Regular price ~~$6.27 AUD~~ Sale price $5.23 AUD Unit price per Each
Wire Thickness (d) 7.00 mm _{(0.276 in.)}	Length (L) 152.0 mm _{(5.984 in.)}	Material Zinc Plated	Drill Hole Size 8.00 mm
Material: Spring Steel Zinc Plated Inside Eye Diameter (D): 30.00 mm Shaft Size Range: 26.00 to 40.00 mm Approx. Bridge Length (D1): 48 mm Category: R Clips - Double Coil - Steel
Part Number: RCL-070-152-ZD Double Coil R Clips - 7x152 mm - Zinc Plated 18 Available Immediately \| Further orders can be expected around Tue, Jul 22, 2025 Regular price $5.23 AUD Regular price ~~$6.27 AUD~~ Sale price $5.23 AUD Unit price per Each View the product page first if you are unsure.
RCL-070-152-ZD --- Double Coil R Clips - 7x152 mm - Zinc Plated Sale RCL-070-152-ZD --- Double Coil R Clips - 7x152 mm - Zinc Plated Regular price $5.23 AUD Regular price ~~$6.27 AUD~~ Sale price $5.23 AUD Unit price per 18 Available Now Sale
Wire Thickness (d) 8.00 mm _{(0.315 in.)}	Length (L) 153.0 mm _{(6.024 in.)}	Material Zinc Plated	Drill Hole Size 9.00 mm	Inside Eye Diameter (D) 30.00 mm	Shaft Size Range 40.00 to 40.00 mm
Material: Spring Steel Zinc Plated Approx. Bridge Length (D1): 50 mm Category: R Clips - Double Coil - Steel
Part Number: RCL-080-153-ZD (50 Pcs) Double Coil R Clips - 8x153 mm - Zinc Plated Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 22, 2025 Regular price $434.05 AUD Regular price Sale price $434.05 AUD Unit price per Per 50
Wire Thickness (d) 8.00 mm _{(0.315 in.)}	Length (L) 153.0 mm _{(6.024 in.)}	Material Zinc Plated	Drill Hole Size 9.00 mm
Material: Spring Steel Zinc Plated Inside Eye Diameter (D): 30.00 mm Shaft Size Range: 40.00 to 40.00 mm Approx. Bridge Length (D1): 50 mm Category: R Clips - Double Coil - Steel
Part Number: RCL-080-153-ZD (50 Pcs) Double Coil R Clips - 8x153 mm - Zinc Plated Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jul 22, 2025 Regular price $434.05 AUD Regular price Sale price $434.05 AUD Unit price per Per 50 View the product page first if you are unsure.
RCL-080-153-ZD (50 Pcs) --- Double Coil R Clips - 8x153 mm - Zinc Plated RCL-080-153-ZD (50 Pcs) --- Double Coil R Clips - 8x153 mm - Zinc Plated Regular price $434.05 AUD Regular price Sale price $434.05 AUD Unit price per Out of stock! Backorder Now
