Collection: Mounts - Levelling Studded - Light Duty

Mounts (With Images)

Levelling Studded

Standard
Swivel

157 Products in this selection

This is a combined category of Light Duty Levelling Studded Mounts.
Use the filters in the table below, or the category tree above to refine the selection. To order any item, simply click the part number for a full product page, then add to your cart.

Additional resources:

A more concise listing may be found on the Smallparts store at Mounts - Levelling Studded - Light Duty. Smallparts promote the most popular MBA products.

Thread Size (A)	Base Diameter (D)	Foot Height (C)	Thread Length (F)	Base Height (E)	Overall Height	Indicative Image
Thread Size (A) 1/4-20 UNC (6.35mm)	Base Diameter (D) 35.1 mm _{(1.382 in.)}	Foot Height (C) 12.7 mm _{(0.5 in.)}	Thread Length (F) 38.1 mm	Base Height (E) 12.7 mm	Overall Height 50.8 mm
Material: Zinc Plated Steel Load Rating: 140 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon Padded
Part Number: MLM-064C-038-CNP-LD Levelling Studded Mounts - 1/4-20 UNC -6.35mm- 35.1x12.7 mm - Zinc Plated Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $11.59 AUD Regular price Sale price $11.59 AUD Unit price per Each
Thread Size (A)	Base Diameter (D)	Foot Height (C)	Thread Length (F)	Indicative Image
Thread Size (A) 1/4-20 UNC (6.35mm)	Base Diameter (D) 35.1 mm _{(1.382 in.)}	Foot Height (C) 12.7 mm _{(0.5 in.)}	Thread Length (F) 38.1 mm
Material: Zinc Plated Steel Base Height (E): 12.7 mm Overall Height: 50.8 mm Load Rating: 140 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon Padded
Part Number: MLM-064C-038-CNP-LD Levelling Studded Mounts - 1/4-20 UNC -6.35mm- 35.1x12.7 mm - Zinc Plated Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $11.59 AUD Regular price Sale price $11.59 AUD Unit price per Each View the product page first if you are unsure.
MLM-064C-038-CNP-LD --- Levelling Studded Mounts - 1/4-20 UNC -6.35mm- 35.1x12.7 mm - Zinc Plated Steel MLM-064C-038-CNP-LD --- Levelling Studded Mounts - 1/4-20 UNC -6.35mm- 35.1x12.7 mm - Zinc Plated Steel Regular price $11.59 AUD Regular price Sale price $11.59 AUD Unit price per Out of stock! Backorder Now
Thread Size (A) 1/4-20 UNC (6.35mm)	Base Diameter (D) 38.1 mm _{(1.5 in.)}	Foot Height (C) 12.7 mm _{(0.5 in.)}	Thread Length (F) 38.1 mm	Base Height (E) 12.7 mm	Overall Height 50.8 mm
Material: Zinc Plated Steel Load Rating: 140 Kg Category: Mounts - Levelling Studded - Light Duty - Rubber Padded
Part Number: MLM-064C-038-C-LDRP Levelling Studded Mounts - 1/4-20 UNC -6.35mm- 38.1x12.7 mm - Zinc Plated Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $12.95 AUD Regular price Sale price $12.95 AUD Unit price per Each
Thread Size (A) 1/4-20 UNC (6.35mm)	Base Diameter (D) 38.1 mm _{(1.5 in.)}	Foot Height (C) 12.7 mm _{(0.5 in.)}	Thread Length (F) 38.1 mm
Material: Zinc Plated Steel Base Height (E): 12.7 mm Overall Height: 50.8 mm Load Rating: 140 Kg Category: Mounts - Levelling Studded - Light Duty - Rubber Padded
Part Number: MLM-064C-038-C-LDRP Levelling Studded Mounts - 1/4-20 UNC -6.35mm- 38.1x12.7 mm - Zinc Plated Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $12.95 AUD Regular price Sale price $12.95 AUD Unit price per Each View the product page first if you are unsure.
MLM-064C-038-C-LDRP --- Levelling Studded Mounts - 1/4-20 UNC -6.35mm- 38.1x12.7 mm - Zinc Plated Steel MLM-064C-038-C-LDRP --- Levelling Studded Mounts - 1/4-20 UNC -6.35mm- 38.1x12.7 mm - Zinc Plated Steel Regular price $12.95 AUD Regular price Sale price $12.95 AUD Unit price per Out of stock! Backorder Now
Thread Size (A) 5/16-18 UNC (7.94mm)	Base Diameter (D) 35.1 mm _{(1.382 in.)}	Foot Height (C) 12.7 mm _{(0.5 in.)}	Thread Length (F) 38.1 mm	Base Height (E) 12.7 mm	Overall Height 50.8 mm
Material: Zinc Plated Steel Load Rating: 140 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon Padded
Part Number: MLM-079C-038-CNP-LD Levelling Studded Mounts - 5/16-18 UNC -7.94mm- 35.1x12.7 mm - Zinc Plated Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $11.41 AUD Regular price Sale price $11.41 AUD Unit price per Each
Thread Size (A) 5/16-18 UNC (7.94mm)	Base Diameter (D) 35.1 mm _{(1.382 in.)}	Foot Height (C) 12.7 mm _{(0.5 in.)}	Thread Length (F) 38.1 mm
Material: Zinc Plated Steel Base Height (E): 12.7 mm Overall Height: 50.8 mm Load Rating: 140 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon Padded
Part Number: MLM-079C-038-CNP-LD Levelling Studded Mounts - 5/16-18 UNC -7.94mm- 35.1x12.7 mm - Zinc Plated Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $11.41 AUD Regular price Sale price $11.41 AUD Unit price per Each View the product page first if you are unsure.
MLM-079C-038-CNP-LD --- Levelling Studded Mounts - 5/16-18 UNC -7.94mm- 35.1x12.7 mm - Zinc Plated Steel MLM-079C-038-CNP-LD --- Levelling Studded Mounts - 5/16-18 UNC -7.94mm- 35.1x12.7 mm - Zinc Plated Steel Regular price $11.41 AUD Regular price Sale price $11.41 AUD Unit price per Out of stock! Backorder Now
Thread Size (A) 5/16-18 UNC (7.94mm)	Base Diameter (D) 38.1 mm _{(1.5 in.)}	Foot Height (C) 12.7 mm _{(0.5 in.)}	Thread Length (F) 38.1 mm	Base Height (E) 12.7 mm	Overall Height 50.8 mm
Material: Zinc Plated Steel Load Rating: 140 Kg Category: Mounts - Levelling Studded - Light Duty - Rubber Padded
Part Number: MLM-079C-038-C-LDRP Levelling Studded Mounts - 5/16-18 UNC -7.94mm- 38.1x12.7 mm - Zinc Plated Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $13.77 AUD Regular price Sale price $13.77 AUD Unit price per Each
Thread Size (A) 5/16-18 UNC (7.94mm)	Base Diameter (D) 38.1 mm _{(1.5 in.)}	Foot Height (C) 12.7 mm _{(0.5 in.)}	Thread Length (F) 38.1 mm
Material: Zinc Plated Steel Base Height (E): 12.7 mm Overall Height: 50.8 mm Load Rating: 140 Kg Category: Mounts - Levelling Studded - Light Duty - Rubber Padded
Part Number: MLM-079C-038-C-LDRP Levelling Studded Mounts - 5/16-18 UNC -7.94mm- 38.1x12.7 mm - Zinc Plated Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $13.77 AUD Regular price Sale price $13.77 AUD Unit price per Each View the product page first if you are unsure.
MLM-079C-038-C-LDRP --- Levelling Studded Mounts - 5/16-18 UNC -7.94mm- 38.1x12.7 mm - Zinc Plated Steel MLM-079C-038-C-LDRP --- Levelling Studded Mounts - 5/16-18 UNC -7.94mm- 38.1x12.7 mm - Zinc Plated Steel Regular price $13.77 AUD Regular price Sale price $13.77 AUD Unit price per Out of stock! Backorder Now
Thread Size (A) 5/16-18 UNC (7.94mm)	Base Diameter (D) 39.1 mm _{(1.539 in.)}	Foot Height (C) 18.3 mm _{(0.72 in.)}	Thread Length (F) 47.8 mm	Base Height (E) 18.2 mm	Overall Height 66.04 mm
Material: Steel Load Rating: 315 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-079C-048-CNY-0LH Levelling Studded Mounts - 5/16-18 UNC -7.94mm- 39.1x18.3 mm - Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $31.23 AUD Regular price Sale price $31.23 AUD Unit price per Each
Thread Size (A) 5/16-18 UNC (7.94mm)	Base Diameter (D) 39.1 mm _{(1.539 in.)}	Foot Height (C) 18.3 mm _{(0.72 in.)}	Thread Length (F) 47.8 mm
Material: Steel Base Height (E): 18.2 mm Overall Height: 66.04 mm Load Rating: 315 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-079C-048-CNY-0LH Levelling Studded Mounts - 5/16-18 UNC -7.94mm- 39.1x18.3 mm - Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $31.23 AUD Regular price Sale price $31.23 AUD Unit price per Each View the product page first if you are unsure.
MLM-079C-048-CNY-0LH --- Levelling Studded Mounts - 5/16-18 UNC -7.94mm- 39.1x18.3 mm - Steel MLM-079C-048-CNY-0LH --- Levelling Studded Mounts - 5/16-18 UNC -7.94mm- 39.1x18.3 mm - Steel Regular price $31.23 AUD Regular price Sale price $31.23 AUD Unit price per Out of stock! Backorder Now
Thread Size (A) 5/16-18 UNC (7.94mm)	Base Diameter (D) 39.1 mm _{(1.539 in.)}	Foot Height (C) 18.3 mm _{(0.72 in.)}	Thread Length (F) 47.8 mm	Base Height (E) 18.2 mm	Overall Height 66.04 mm
Material: Stainless Steel Load Rating: 315 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-079C-048-S3NY-0LH Levelling Studded Mounts - 5/16-18 UNC -7.94mm- 39.1x18.3 mm - Stainless Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $44.59 AUD Regular price Sale price $44.59 AUD Unit price per Each
Thread Size (A) 5/16-18 UNC (7.94mm)	Base Diameter (D) 39.1 mm _{(1.539 in.)}	Foot Height (C) 18.3 mm _{(0.72 in.)}	Thread Length (F) 47.8 mm
Material: Stainless Steel Base Height (E): 18.2 mm Overall Height: 66.04 mm Load Rating: 315 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-079C-048-S3NY-0LH Levelling Studded Mounts - 5/16-18 UNC -7.94mm- 39.1x18.3 mm - Stainless Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $44.59 AUD Regular price Sale price $44.59 AUD Unit price per Each View the product page first if you are unsure.
MLM-079C-048-S3NY-0LH --- Levelling Studded Mounts - 5/16-18 UNC -7.94mm- 39.1x18.3 mm - Stainless Steel MLM-079C-048-S3NY-0LH --- Levelling Studded Mounts - 5/16-18 UNC -7.94mm- 39.1x18.3 mm - Stainless Steel Regular price $44.59 AUD Regular price Sale price $44.59 AUD Unit price per Out of stock! Backorder Now
Thread Size (A) 5/16-18 UNC (7.94mm)	Base Diameter (D) 39.1 mm _{(1.539 in.)}	Foot Height (C) 18.3 mm _{(0.72 in.)}	Thread Length (F) 73.2 mm	Base Height (E) 18.2 mm	Overall Height 91.44 mm
Material: Stainless Steel Load Rating: 315 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-079C-073-S3NY-0LH Levelling Studded Mounts - 5/16-18 UNC -7.94mm- 39.1x18.3 mm - Stainless Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $32.59 AUD Regular price Sale price $32.59 AUD Unit price per Each
Thread Size (A) 5/16-18 UNC (7.94mm)	Base Diameter (D) 39.1 mm _{(1.539 in.)}	Foot Height (C) 18.3 mm _{(0.72 in.)}	Thread Length (F) 73.2 mm
Material: Stainless Steel Base Height (E): 18.2 mm Overall Height: 91.44 mm Load Rating: 315 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-079C-073-S3NY-0LH Levelling Studded Mounts - 5/16-18 UNC -7.94mm- 39.1x18.3 mm - Stainless Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $32.59 AUD Regular price Sale price $32.59 AUD Unit price per Each View the product page first if you are unsure.
MLM-079C-073-S3NY-0LH --- Levelling Studded Mounts - 5/16-18 UNC -7.94mm- 39.1x18.3 mm - Stainless Steel MLM-079C-073-S3NY-0LH --- Levelling Studded Mounts - 5/16-18 UNC -7.94mm- 39.1x18.3 mm - Stainless Steel Regular price $32.59 AUD Regular price Sale price $32.59 AUD Unit price per Out of stock! Backorder Now
Thread Size (A) M8 (8x1.25mm)	Base Diameter (D) 39.1 mm _{(1.539 in.)}	Foot Height (C) 18.3 mm _{(0.72 in.)}	Thread Length (F) 38.0 mm	Base Height (E) 30.0 mm	Overall Height 68.00 mm
Material: Steel Load Rating: 315 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-080M-038-CNY-0LH-039 Levelling Studded Mounts - M8 -8x1.25mm- 39.1x18.3 mm - Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $34.95 AUD Regular price Sale price $34.95 AUD Unit price per Each
Thread Size (A) M8 (8x1.25mm)	Base Diameter (D) 39.1 mm _{(1.539 in.)}	Foot Height (C) 18.3 mm _{(0.72 in.)}	Thread Length (F) 38.0 mm
Material: Steel Base Height (E): 30.0 mm Overall Height: 68.00 mm Load Rating: 315 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-080M-038-CNY-0LH-039 Levelling Studded Mounts - M8 -8x1.25mm- 39.1x18.3 mm - Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $34.95 AUD Regular price Sale price $34.95 AUD Unit price per Each View the product page first if you are unsure.
MLM-080M-038-CNY-0LH-039 --- Levelling Studded Mounts - M8 -8x1.25mm- 39.1x18.3 mm - Steel MLM-080M-038-CNY-0LH-039 --- Levelling Studded Mounts - M8 -8x1.25mm- 39.1x18.3 mm - Steel Regular price $34.95 AUD Regular price Sale price $34.95 AUD Unit price per Out of stock! Backorder Now
Thread Size (A) M8 (8x1.25mm)	Base Diameter (D) 39.1 mm _{(1.539 in.)}	Foot Height (C) 18.3 mm _{(0.72 in.)}	Thread Length (F) 38.0 mm	Base Height (E) 30.0 mm	Overall Height 68.00 mm
Material: Stainless Steel Load Rating: 315 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-080M-038-S3NY-0LH-039 Levelling Studded Mounts - M8 -8x1.25mm- 39.1x18.3 mm - Stainless Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $42.23 AUD Regular price Sale price $42.23 AUD Unit price per Each
Thread Size (A) M8 (8x1.25mm)	Base Diameter (D) 39.1 mm _{(1.539 in.)}	Foot Height (C) 18.3 mm _{(0.72 in.)}	Thread Length (F) 38.0 mm
Material: Stainless Steel Base Height (E): 30.0 mm Overall Height: 68.00 mm Load Rating: 315 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-080M-038-S3NY-0LH-039 Levelling Studded Mounts - M8 -8x1.25mm- 39.1x18.3 mm - Stainless Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $42.23 AUD Regular price Sale price $42.23 AUD Unit price per Each View the product page first if you are unsure.
MLM-080M-038-S3NY-0LH-039 --- Levelling Studded Mounts - M8 -8x1.25mm- 39.1x18.3 mm - Stainless Steel MLM-080M-038-S3NY-0LH-039 --- Levelling Studded Mounts - M8 -8x1.25mm- 39.1x18.3 mm - Stainless Steel Regular price $42.23 AUD Regular price Sale price $42.23 AUD Unit price per Out of stock! Backorder Now
Thread Size (A) M8 (8x1.25mm)	Base Diameter (D) 39.1 mm _{(1.539 in.)}	Foot Height (C) 18.3 mm _{(0.72 in.)}	Thread Length (F) 64.0 mm	Base Height (E) 30.0 mm	Overall Height 94.00 mm
Material: Steel Load Rating: 315 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-080M-064-CNY-0LH Levelling Studded Mounts - M8 -8x1.25mm- 39.1x18.3 mm - Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $37.32 AUD Regular price Sale price $37.32 AUD Unit price per Each
Thread Size (A) M8 (8x1.25mm)	Base Diameter (D) 39.1 mm _{(1.539 in.)}	Foot Height (C) 18.3 mm _{(0.72 in.)}	Thread Length (F) 64.0 mm
Material: Steel Base Height (E): 30.0 mm Overall Height: 94.00 mm Load Rating: 315 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-080M-064-CNY-0LH Levelling Studded Mounts - M8 -8x1.25mm- 39.1x18.3 mm - Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $37.32 AUD Regular price Sale price $37.32 AUD Unit price per Each View the product page first if you are unsure.
MLM-080M-064-CNY-0LH --- Levelling Studded Mounts - M8 -8x1.25mm- 39.1x18.3 mm - Steel MLM-080M-064-CNY-0LH --- Levelling Studded Mounts - M8 -8x1.25mm- 39.1x18.3 mm - Steel Regular price $37.32 AUD Regular price Sale price $37.32 AUD Unit price per Out of stock! Backorder Now
Thread Size (A) M8 (8x1.25mm)	Base Diameter (D) 48.8 mm _{(1.921 in.)}	Foot Height (C) 18.3 mm _{(0.72 in.)}	Thread Length (F) 38.0 mm	Base Height (E) 30.0 mm	Overall Height 68.00 mm
Material: Steel Load Rating: 315 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-080M-038-CNY-0LH-049 Levelling Studded Mounts - M8 -8x1.25mm- 48.8x18.3 mm - Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $38.14 AUD Regular price Sale price $38.14 AUD Unit price per Each
Thread Size (A) M8 (8x1.25mm)	Base Diameter (D) 48.8 mm _{(1.921 in.)}	Foot Height (C) 18.3 mm _{(0.72 in.)}	Thread Length (F) 38.0 mm
Material: Steel Base Height (E): 30.0 mm Overall Height: 68.00 mm Load Rating: 315 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-080M-038-CNY-0LH-049 Levelling Studded Mounts - M8 -8x1.25mm- 48.8x18.3 mm - Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $38.14 AUD Regular price Sale price $38.14 AUD Unit price per Each View the product page first if you are unsure.
MLM-080M-038-CNY-0LH-049 --- Levelling Studded Mounts - M8 -8x1.25mm- 48.8x18.3 mm - Steel MLM-080M-038-CNY-0LH-049 --- Levelling Studded Mounts - M8 -8x1.25mm- 48.8x18.3 mm - Steel Regular price $38.14 AUD Regular price Sale price $38.14 AUD Unit price per Out of stock! Backorder Now
Thread Size (A) M8 (8x1.25mm)	Base Diameter (D) 50.00 mm _{(1.969 in.)}	Foot Height (C) 29.50 mm _{(1.161 in.)}	Thread Length (F) 50.00 mm	Base Height (E) 29.5 mm	Overall Height 79.5 mm
Material: Stainless Steel 304 (Similar to A2, 18-8) HRB80 Load Rating: 210 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-080M-050-S4NY-0LH (4 Pcs) Levelling Studded Mounts - M8 -8x1.25mm- 50x29.5 mm - Stainless Steel 304 Similar to A2, 18-8 HRB80 Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 17, 2025 Regular price $28.77 AUD Regular price Sale price $28.77 AUD Unit price per Per 4
Thread Size (A) M8 (8x1.25mm)	Base Diameter (D) 50.00 mm _{(1.969 in.)}	Foot Height (C) 29.50 mm _{(1.161 in.)}	Thread Length (F) 50.00 mm
Material: Stainless Steel 304 (Similar to A2, 18-8) HRB80 Base Height (E): 29.5 mm Overall Height: 79.5 mm Load Rating: 210 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-080M-050-S4NY-0LH (4 Pcs) Levelling Studded Mounts - M8 -8x1.25mm- 50x29.5 mm - Stainless Steel 304 Similar to A2, 18-8 HRB80 Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 17, 2025 Regular price $28.77 AUD Regular price Sale price $28.77 AUD Unit price per Per 4 View the product page first if you are unsure.
MLM-080M-050-S4NY-0LH (4 Pcs) --- Levelling Studded Mounts - M8 -8x1.25mm- 50x29.5 mm - Stainless Steel 304 Similar to A2, 18-8 HRB80 MLM-080M-050-S4NY-0LH (4 Pcs) --- Levelling Studded Mounts - M8 -8x1.25mm- 50x29.5 mm - Stainless Steel 304 Similar to A2, 18-8 HRB80 Regular price $28.77 AUD Regular price Sale price $28.77 AUD Unit price per Out of stock! Backorder Now
Thread Size (A) M8 (8x1.25mm)	Base Diameter (D) 50.00 mm _{(1.969 in.)}	Foot Height (C) 29.50 mm _{(1.161 in.)}	Thread Length (F) 50.00 mm	Base Height (E) 29.5 mm	Overall Height 79.5 mm
Material: Steel Load Rating: 180 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-080M-050-CNY-0LH Levelling Studded Mounts - M8 -8x1.25mm- 50x29.5 mm - Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 17, 2025 Regular price $5.59 AUD Regular price Sale price $5.59 AUD Unit price per Each
Thread Size (A) M8 (8x1.25mm)	Base Diameter (D) 50.00 mm _{(1.969 in.)}	Foot Height (C) 29.50 mm _{(1.161 in.)}	Thread Length (F) 50.00 mm
Material: Steel Base Height (E): 29.5 mm Overall Height: 79.5 mm Load Rating: 180 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-080M-050-CNY-0LH Levelling Studded Mounts - M8 -8x1.25mm- 50x29.5 mm - Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 17, 2025 Regular price $5.59 AUD Regular price Sale price $5.59 AUD Unit price per Each View the product page first if you are unsure.
MLM-080M-050-CNY-0LH --- Levelling Studded Mounts - M8 -8x1.25mm- 50x29.5 mm - Steel MLM-080M-050-CNY-0LH --- Levelling Studded Mounts - M8 -8x1.25mm- 50x29.5 mm - Steel Regular price $5.59 AUD Regular price Sale price $5.59 AUD Unit price per Out of stock! Backorder Now
Thread Size (A) M8 (8x1.25mm)	Base Diameter (D) 50.00 mm _{(1.969 in.)}	Foot Height (C) 29.50 mm _{(1.161 in.)}	Thread Length (F) 80.00 mm	Base Height (E) 29.5 mm	Overall Height 109.5 mm
Material: Stainless Steel 304 (Similar to A2, 18-8) HRB80 Load Rating: 210 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-080M-080-S4NY-0LH Levelling Studded Mounts - M8 -8x1.25mm- 50x29.5 mm - Stainless Steel 304 Similar to A2, 18-8 HRB80 Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 17, 2025 Regular price $8.77 AUD Regular price Sale price $8.77 AUD Unit price per Each
Thread Size (A) M8 (8x1.25mm)	Base Diameter (D) 50.00 mm _{(1.969 in.)}	Foot Height (C) 29.50 mm _{(1.161 in.)}	Thread Length (F) 80.00 mm
Material: Stainless Steel 304 (Similar to A2, 18-8) HRB80 Base Height (E): 29.5 mm Overall Height: 109.5 mm Load Rating: 210 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-080M-080-S4NY-0LH Levelling Studded Mounts - M8 -8x1.25mm- 50x29.5 mm - Stainless Steel 304 Similar to A2, 18-8 HRB80 Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 17, 2025 Regular price $8.77 AUD Regular price Sale price $8.77 AUD Unit price per Each View the product page first if you are unsure.
MLM-080M-080-S4NY-0LH --- Levelling Studded Mounts - M8 -8x1.25mm- 50x29.5 mm - Stainless Steel 304 Similar to A2, 18-8 HRB80 MLM-080M-080-S4NY-0LH --- Levelling Studded Mounts - M8 -8x1.25mm- 50x29.5 mm - Stainless Steel 304 Similar to A2, 18-8 HRB80 Regular price $8.77 AUD Regular price Sale price $8.77 AUD Unit price per Out of stock! Backorder Now
Thread Size (A) M8 (8x1.25mm)	Base Diameter (D) 50.00 mm _{(1.969 in.)}	Foot Height (C) 29.50 mm _{(1.161 in.)}	Thread Length (F) 80.00 mm	Base Height (E) 29.5 mm	Overall Height 109.5 mm
Material: Steel Load Rating: 180 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-080M-080-CNY-0LH Levelling Studded Mounts - M8 -8x1.25mm- 50x29.5 mm - Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 17, 2025 Regular price $5.77 AUD Regular price Sale price $5.77 AUD Unit price per Each
Thread Size (A) M8 (8x1.25mm)	Base Diameter (D) 50.00 mm _{(1.969 in.)}	Foot Height (C) 29.50 mm _{(1.161 in.)}	Thread Length (F) 80.00 mm
Material: Steel Base Height (E): 29.5 mm Overall Height: 109.5 mm Load Rating: 180 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-080M-080-CNY-0LH Levelling Studded Mounts - M8 -8x1.25mm- 50x29.5 mm - Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 17, 2025 Regular price $5.77 AUD Regular price Sale price $5.77 AUD Unit price per Each View the product page first if you are unsure.
MLM-080M-080-CNY-0LH --- Levelling Studded Mounts - M8 -8x1.25mm- 50x29.5 mm - Steel MLM-080M-080-CNY-0LH --- Levelling Studded Mounts - M8 -8x1.25mm- 50x29.5 mm - Steel Regular price $5.77 AUD Regular price Sale price $5.77 AUD Unit price per Out of stock! Backorder Now
Thread Size (A) 3/8-16 UNC (9.53mm)	Base Diameter (D) 39.1 mm _{(1.539 in.)}	Foot Height (C) 18.3 mm _{(0.72 in.)}	Thread Length (F) 47.8 mm	Base Height (E) 18.2 mm	Overall Height 66.04 mm
Material: Steel Load Rating: 315 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-095C-048-CNY-0LH Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 39.1x18.3 mm - Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $102.77 AUD Regular price Sale price $102.77 AUD Unit price per Each
Thread Size (A) 3/8-16 UNC (9.53mm)	Base Diameter (D) 39.1 mm _{(1.539 in.)}	Foot Height (C) 18.3 mm _{(0.72 in.)}	Thread Length (F) 47.8 mm
Material: Steel Base Height (E): 18.2 mm Overall Height: 66.04 mm Load Rating: 315 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-095C-048-CNY-0LH Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 39.1x18.3 mm - Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $102.77 AUD Regular price Sale price $102.77 AUD Unit price per Each View the product page first if you are unsure.
MLM-095C-048-CNY-0LH --- Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 39.1x18.3 mm - Steel MLM-095C-048-CNY-0LH --- Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 39.1x18.3 mm - Steel Regular price $102.77 AUD Regular price Sale price $102.77 AUD Unit price per Out of stock! Backorder Now
Thread Size (A) 3/8-16 UNC (9.53mm)	Base Diameter (D) 39.1 mm _{(1.539 in.)}	Foot Height (C) 18.3 mm _{(0.72 in.)}	Thread Length (F) 47.8 mm	Base Height (E) 18.2 mm	Overall Height 66.04 mm
Material: Stainless Steel Load Rating: 315 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-095C-048-S3NY-0LH Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 39.1x18.3 mm - Stainless Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $44.05 AUD Regular price Sale price $44.05 AUD Unit price per Each
Thread Size (A) 3/8-16 UNC (9.53mm)	Base Diameter (D) 39.1 mm _{(1.539 in.)}	Foot Height (C) 18.3 mm _{(0.72 in.)}	Thread Length (F) 47.8 mm
Material: Stainless Steel Base Height (E): 18.2 mm Overall Height: 66.04 mm Load Rating: 315 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-095C-048-S3NY-0LH Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 39.1x18.3 mm - Stainless Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $44.05 AUD Regular price Sale price $44.05 AUD Unit price per Each View the product page first if you are unsure.
MLM-095C-048-S3NY-0LH --- Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 39.1x18.3 mm - Stainless Steel MLM-095C-048-S3NY-0LH --- Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 39.1x18.3 mm - Stainless Steel Regular price $44.05 AUD Regular price Sale price $44.05 AUD Unit price per Out of stock! Backorder Now
Thread Size (A) 3/8-16 UNC (9.53mm)	Base Diameter (D) 39.1 mm _{(1.539 in.)}	Foot Height (C) 18.3 mm _{(0.72 in.)}	Thread Length (F) 73.2 mm	Base Height (E) 18.2 mm	Overall Height 91.44 mm
Material: Steel Load Rating: 315 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-095C-073-CNY-0LH Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 39.1x18.3 mm - Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $25.23 AUD Regular price Sale price $25.23 AUD Unit price per Each
Thread Size (A) 3/8-16 UNC (9.53mm)	Base Diameter (D) 39.1 mm _{(1.539 in.)}	Foot Height (C) 18.3 mm _{(0.72 in.)}	Thread Length (F) 73.2 mm
Material: Steel Base Height (E): 18.2 mm Overall Height: 91.44 mm Load Rating: 315 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-095C-073-CNY-0LH Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 39.1x18.3 mm - Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $25.23 AUD Regular price Sale price $25.23 AUD Unit price per Each View the product page first if you are unsure.
MLM-095C-073-CNY-0LH --- Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 39.1x18.3 mm - Steel MLM-095C-073-CNY-0LH --- Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 39.1x18.3 mm - Steel Regular price $25.23 AUD Regular price Sale price $25.23 AUD Unit price per Out of stock! Backorder Now
Thread Size (A) 3/8-16 UNC (9.53mm)	Base Diameter (D) 39.1 mm _{(1.539 in.)}	Foot Height (C) 18.3 mm _{(0.72 in.)}	Thread Length (F) 73.2 mm	Base Height (E) 18.2 mm	Overall Height 91.44 mm
Material: Stainless Steel Load Rating: 315 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-095C-073-S3NY-0LH Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 39.1x18.3 mm - Stainless Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $50.14 AUD Regular price Sale price $50.14 AUD Unit price per Each
Thread Size (A) 3/8-16 UNC (9.53mm)	Base Diameter (D) 39.1 mm _{(1.539 in.)}	Foot Height (C) 18.3 mm _{(0.72 in.)}	Thread Length (F) 73.2 mm
Material: Stainless Steel Base Height (E): 18.2 mm Overall Height: 91.44 mm Load Rating: 315 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-095C-073-S3NY-0LH Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 39.1x18.3 mm - Stainless Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $50.14 AUD Regular price Sale price $50.14 AUD Unit price per Each View the product page first if you are unsure.
MLM-095C-073-S3NY-0LH --- Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 39.1x18.3 mm - Stainless Steel MLM-095C-073-S3NY-0LH --- Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 39.1x18.3 mm - Stainless Steel Regular price $50.14 AUD Regular price Sale price $50.14 AUD Unit price per Out of stock! Backorder Now
Thread Size (A) 3/8-16 UNC (9.53mm)	Base Diameter (D) 50.8 mm _{(2 in.)}	Foot Height (C) 12.7 mm _{(0.5 in.)}	Thread Length (F) 50.8 mm	Base Height (E) 12.7 mm	Overall Height 63.5 mm
Material: Zinc Plated Steel Load Rating: 140 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon Padded
Part Number: MLM-095C-051-CNP-LD Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 50.8x12.7 mm - Zinc Plated Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $18.23 AUD Regular price Sale price $18.23 AUD Unit price per Each
Thread Size (A) 3/8-16 UNC (9.53mm)	Base Diameter (D) 50.8 mm _{(2 in.)}	Foot Height (C) 12.7 mm _{(0.5 in.)}	Thread Length (F) 50.8 mm
Material: Zinc Plated Steel Base Height (E): 12.7 mm Overall Height: 63.5 mm Load Rating: 140 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon Padded
Part Number: MLM-095C-051-CNP-LD Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 50.8x12.7 mm - Zinc Plated Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $18.23 AUD Regular price Sale price $18.23 AUD Unit price per Each View the product page first if you are unsure.
MLM-095C-051-CNP-LD --- Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 50.8x12.7 mm - Zinc Plated Steel MLM-095C-051-CNP-LD --- Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 50.8x12.7 mm - Zinc Plated Steel Regular price $18.23 AUD Regular price Sale price $18.23 AUD Unit price per Out of stock! Backorder Now
Thread Size (A) 3/8-16 UNC (9.53mm)	Base Diameter (D) 50.8 mm _{(2 in.)}	Foot Height (C) 12.7 mm _{(0.5 in.)}	Thread Length (F) 50.8 mm	Base Height (E) 12.7 mm	Overall Height 63.5 mm
Material: Zinc Plated Steel Load Rating: 140 Kg Category: Mounts - Levelling Studded - Light Duty - Rubber Padded
Part Number: MLM-095C-051-C-LDRP Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 50.8x12.7 mm - Zinc Plated Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $21.95 AUD Regular price Sale price $21.95 AUD Unit price per Each
Thread Size (A) 3/8-16 UNC (9.53mm)	Base Diameter (D) 50.8 mm _{(2 in.)}	Foot Height (C) 12.7 mm _{(0.5 in.)}	Thread Length (F) 50.8 mm
Material: Zinc Plated Steel Base Height (E): 12.7 mm Overall Height: 63.5 mm Load Rating: 140 Kg Category: Mounts - Levelling Studded - Light Duty - Rubber Padded
Part Number: MLM-095C-051-C-LDRP Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 50.8x12.7 mm - Zinc Plated Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $21.95 AUD Regular price Sale price $21.95 AUD Unit price per Each View the product page first if you are unsure.
MLM-095C-051-C-LDRP --- Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 50.8x12.7 mm - Zinc Plated Steel MLM-095C-051-C-LDRP --- Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 50.8x12.7 mm - Zinc Plated Steel Regular price $21.95 AUD Regular price Sale price $21.95 AUD Unit price per Out of stock! Backorder Now
Thread Size (A) 3/8-16 UNC (9.53mm)	Base Diameter (D) 78.7 mm _{(3.098 in.)}	Foot Height (C) 18.3 mm _{(0.72 in.)}	Thread Length (F) 61.5 mm	Base Height (E) 29.9 mm	Overall Height 91.44 mm
Material: Stainless Steel Load Rating: 900 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-095C-062-S3NY-0LH Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 78.7x18.3 mm - Stainless Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $30.77 AUD Regular price Sale price $30.77 AUD Unit price per Each
Thread Size (A) 3/8-16 UNC (9.53mm)	Base Diameter (D) 78.7 mm _{(3.098 in.)}	Foot Height (C) 18.3 mm _{(0.72 in.)}	Thread Length (F) 61.5 mm
Material: Stainless Steel Base Height (E): 29.9 mm Overall Height: 91.44 mm Load Rating: 900 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-095C-062-S3NY-0LH Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 78.7x18.3 mm - Stainless Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $30.77 AUD Regular price Sale price $30.77 AUD Unit price per Each View the product page first if you are unsure.
MLM-095C-062-S3NY-0LH --- Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 78.7x18.3 mm - Stainless Steel MLM-095C-062-S3NY-0LH --- Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 78.7x18.3 mm - Stainless Steel Regular price $30.77 AUD Regular price Sale price $30.77 AUD Unit price per Out of stock! Backorder Now
Thread Size (A) 3/8-16 UNC (9.53mm)	Base Diameter (D) 78.7 mm _{(3.098 in.)}	Foot Height (C) 18.3 mm _{(0.72 in.)}	Thread Length (F) 61.5 mm	Base Height (E) 29.9 mm	Overall Height 91.44 mm
Material: Steel Load Rating: 900 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-095C-062-CNY-0LH Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 78.7x18.3 mm - Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $32.32 AUD Regular price Sale price $32.32 AUD Unit price per Each
Thread Size (A) 3/8-16 UNC (9.53mm)	Base Diameter (D) 78.7 mm _{(3.098 in.)}	Foot Height (C) 18.3 mm _{(0.72 in.)}	Thread Length (F) 61.5 mm
Material: Steel Base Height (E): 29.9 mm Overall Height: 91.44 mm Load Rating: 900 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-095C-062-CNY-0LH Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 78.7x18.3 mm - Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $32.32 AUD Regular price Sale price $32.32 AUD Unit price per Each View the product page first if you are unsure.
MLM-095C-062-CNY-0LH --- Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 78.7x18.3 mm - Steel MLM-095C-062-CNY-0LH --- Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 78.7x18.3 mm - Steel Regular price $32.32 AUD Regular price Sale price $32.32 AUD Unit price per Out of stock! Backorder Now
Thread Size (A) 3/8-16 UNC (9.53mm)	Base Diameter (D) 78.7 mm _{(3.098 in.)}	Foot Height (C) 18.3 mm _{(0.72 in.)}	Thread Length (F) 61.5 mm	Base Height (E) 29.97 mm	Overall Height 79.8 mm
Material: Stainless Steel Load Rating: 900 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-095C-062-S3NY-2LH Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 78.7x18.3 mm - Stainless Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $53.95 AUD Regular price Sale price $53.95 AUD Unit price per Each
Thread Size (A) 3/8-16 UNC (9.53mm)	Base Diameter (D) 78.7 mm _{(3.098 in.)}	Foot Height (C) 18.3 mm _{(0.72 in.)}	Thread Length (F) 61.5 mm
Material: Stainless Steel Base Height (E): 29.97 mm Overall Height: 79.8 mm Load Rating: 900 Kg Category: Mounts - Levelling Studded - Light Duty - Nylon
Part Number: MLM-095C-062-S3NY-2LH Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 78.7x18.3 mm - Stainless Steel Out of Stock \| Backorder Now \| Orders can be expected around Tue, Jun 03, 2025 Regular price $53.95 AUD Regular price Sale price $53.95 AUD Unit price per Each View the product page first if you are unsure.
MLM-095C-062-S3NY-2LH --- Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 78.7x18.3 mm - Stainless Steel MLM-095C-062-S3NY-2LH --- Levelling Studded Mounts - 3/8-16 UNC -9.53mm- 78.7x18.3 mm - Stainless Steel Regular price $53.95 AUD Regular price Sale price $53.95 AUD Unit price per Out of stock! Backorder Now
