15 Products in this selection

PCD in mm = No. of Teeth x 0.8. 20 Degree Pressure Angle.
The diameter increases by 0.5mm per tooth
Module 0.8. Approximately 2.51mm between the teeth.

Additional resources:
Module 0.8 Gear Racks

A more concise listing may be found on the Smallparts store at Gears - Spur - Standard - Module 0.8 - Plastic - Standard. Smallparts promote the most popular MBA products.

Teeth	Pitch Circle Diameter (PD)	Bore (d)	Outside Diameter (OD)	Face Width (FW)
Teeth 12	Pitch Circle Diameter (PD) 9.20 mm _{(0.362 in.)}	Bore (d) 3.000 mm _{(0.118 in.)}	Outside Diameter (OD) 10.80 mm	Face Width (FW) 4.00 mm
Material: Acetal Locking Method: No Set Screw Quality: No Insert
Part Number: G009B-12-M08-040-030-A-P Spur Gears - 12 tooth - 9.2x3 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Mon, Jun 30, 2025 Regular price $6.77 AUD Regular price Sale price $6.77 AUD Unit price per Each
Teeth	Pitch Circle Diameter (PD)	Bore (d)	Outside Diameter (OD)	Indicative Image
Teeth 12	Pitch Circle Diameter (PD) 9.20 mm _{(0.362 in.)}	Bore (d) 3.000 mm _{(0.118 in.)}	Outside Diameter (OD) 10.80 mm
Material: Acetal Face Width (FW): 4.00 mm Locking Method: No Set Screw Quality: No Insert
Part Number: G009B-12-M08-040-030-A-P Spur Gears - 12 tooth - 9.2x3 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Mon, Jun 30, 2025 Regular price $6.77 AUD Regular price Sale price $6.77 AUD Unit price per Each View the product page first if you are unsure.
G009B-12-M08-040-030-A-P --- Spur Gears - 12 tooth - 9.2x3 mm - Acetal G009B-12-M08-040-030-A-P --- Spur Gears - 12 tooth - 9.2x3 mm - Acetal Regular price $6.77 AUD Regular price Sale price $6.77 AUD Unit price per Out of stock! Backorder Now
Teeth 15	Pitch Circle Diameter (PD) 12.00 mm _{(0.472 in.)}	Bore (d) 3.000 mm _{(0.118 in.)}	Outside Diameter (OD) 13.60 mm	Face Width (FW) 4.00 mm
Material: Acetal Locking Method: No Set Screw Quality: No Insert
Part Number: G012B-15-M08-040-030-A-P Spur Gears - 15 tooth - 12x3 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Mon, Jun 30, 2025 Regular price $7.41 AUD Regular price Sale price $7.41 AUD Unit price per Each
Teeth 15	Pitch Circle Diameter (PD) 12.00 mm _{(0.472 in.)}	Bore (d) 3.000 mm _{(0.118 in.)}	Outside Diameter (OD) 13.60 mm
Material: Acetal Face Width (FW): 4.00 mm Locking Method: No Set Screw Quality: No Insert
Part Number: G012B-15-M08-040-030-A-P Spur Gears - 15 tooth - 12x3 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Mon, Jun 30, 2025 Regular price $7.41 AUD Regular price Sale price $7.41 AUD Unit price per Each View the product page first if you are unsure.
G012B-15-M08-040-030-A-P --- Spur Gears - 15 tooth - 12x3 mm - Acetal G012B-15-M08-040-030-A-P --- Spur Gears - 15 tooth - 12x3 mm - Acetal Regular price $7.41 AUD Regular price Sale price $7.41 AUD Unit price per Out of stock! Backorder Now
Teeth 16	Pitch Circle Diameter (PD) 12.80 mm _{(0.504 in.)}	Bore (d) 4.000 mm _{(0.157 in.)}	Outside Diameter (OD) 14.40 mm	Face Width (FW) 4.00 mm
Material: Acetal Locking Method: No Set Screw Quality: No Insert
Part Number: G013B-16-M08-040-040-A-P Spur Gears - 16 tooth - 12.8x4 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Mon, Jun 30, 2025 Regular price $7.68 AUD Regular price Sale price $7.68 AUD Unit price per Each
Teeth 16	Pitch Circle Diameter (PD) 12.80 mm _{(0.504 in.)}	Bore (d) 4.000 mm _{(0.157 in.)}	Outside Diameter (OD) 14.40 mm
Material: Acetal Face Width (FW): 4.00 mm Locking Method: No Set Screw Quality: No Insert
Part Number: G013B-16-M08-040-040-A-P Spur Gears - 16 tooth - 12.8x4 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Mon, Jun 30, 2025 Regular price $7.68 AUD Regular price Sale price $7.68 AUD Unit price per Each View the product page first if you are unsure.
G013B-16-M08-040-040-A-P --- Spur Gears - 16 tooth - 12.8x4 mm - Acetal G013B-16-M08-040-040-A-P --- Spur Gears - 16 tooth - 12.8x4 mm - Acetal Regular price $7.68 AUD Regular price Sale price $7.68 AUD Unit price per Out of stock! Backorder Now
Teeth 24	Pitch Circle Diameter (PD) 19.20 mm _{(0.756 in.)}	Bore (d) 5.000 mm _{(0.197 in.)}	Outside Diameter (OD) 20.80 mm	Face Width (FW) 4.00 mm
Material: Acetal Locking Method: No Set Screw Quality: No Insert
Part Number: G019B-24-M08-040-050-A-P Spur Gears - 24 tooth - 19.2x5 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Mon, Jun 30, 2025 Regular price $9.68 AUD Regular price Sale price $9.68 AUD Unit price per Each
Teeth 24	Pitch Circle Diameter (PD) 19.20 mm _{(0.756 in.)}	Bore (d) 5.000 mm _{(0.197 in.)}	Outside Diameter (OD) 20.80 mm
Material: Acetal Face Width (FW): 4.00 mm Locking Method: No Set Screw Quality: No Insert
Part Number: G019B-24-M08-040-050-A-P Spur Gears - 24 tooth - 19.2x5 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Mon, Jun 30, 2025 Regular price $9.68 AUD Regular price Sale price $9.68 AUD Unit price per Each View the product page first if you are unsure.
G019B-24-M08-040-050-A-P --- Spur Gears - 24 tooth - 19.2x5 mm - Acetal G019B-24-M08-040-050-A-P --- Spur Gears - 24 tooth - 19.2x5 mm - Acetal Regular price $9.68 AUD Regular price Sale price $9.68 AUD Unit price per Out of stock! Backorder Now
Teeth 25	Pitch Circle Diameter (PD) 20.00 mm _{(0.787 in.)}	Bore (d) 5.000 mm _{(0.197 in.)}	Outside Diameter (OD) 21.60 mm	Face Width (FW) 4.00 mm
Material: Acetal Locking Method: No Set Screw Quality: No Insert
Part Number: G020B-25-M08-040-050-A-P Spur Gears - 25 tooth - 20x5 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Mon, Jun 30, 2025 Regular price $10.14 AUD Regular price Sale price $10.14 AUD Unit price per Each
Teeth 25	Pitch Circle Diameter (PD) 20.00 mm _{(0.787 in.)}	Bore (d) 5.000 mm _{(0.197 in.)}	Outside Diameter (OD) 21.60 mm
Material: Acetal Face Width (FW): 4.00 mm Locking Method: No Set Screw Quality: No Insert
Part Number: G020B-25-M08-040-050-A-P Spur Gears - 25 tooth - 20x5 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Mon, Jun 30, 2025 Regular price $10.14 AUD Regular price Sale price $10.14 AUD Unit price per Each View the product page first if you are unsure.
G020B-25-M08-040-050-A-P --- Spur Gears - 25 tooth - 20x5 mm - Acetal G020B-25-M08-040-050-A-P --- Spur Gears - 25 tooth - 20x5 mm - Acetal Regular price $10.14 AUD Regular price Sale price $10.14 AUD Unit price per Out of stock! Backorder Now
Teeth 30	Pitch Circle Diameter (PD) 24.00 mm _{(0.945 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Outside Diameter (OD) 25.60 mm	Face Width (FW) 4.00 mm
Material: Acetal Locking Method: No Set Screw Quality: No Insert
Part Number: G024B-30-M08-040-060-A-P (2 Pcs) Spur Gears - 30 tooth - 24x6 mm - Acetal 1 pack (2 pcs) Available Immediately \| Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity Regular price $12.00 AUD Regular price ~~$22.80 AUD~~ Sale price $12.00 AUD Unit price per Per 2
Teeth 30	Pitch Circle Diameter (PD) 24.00 mm _{(0.945 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Outside Diameter (OD) 25.60 mm
Material: Acetal Face Width (FW): 4.00 mm Locking Method: No Set Screw Quality: No Insert
Part Number: G024B-30-M08-040-060-A-P (2 Pcs) Spur Gears - 30 tooth - 24x6 mm - Acetal 1 pack (2 pcs) Available Immediately \| Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity Regular price $12.00 AUD Regular price ~~$22.80 AUD~~ Sale price $12.00 AUD Unit price per Per 2
G024B-30-M08-040-060-A-P (2 Pcs) --- Spur Gears - 30 tooth - 24x6 mm - Acetal Sale G024B-30-M08-040-060-A-P (2 Pcs) --- Spur Gears - 30 tooth - 24x6 mm - Acetal Regular price $12.00 AUD Regular price ~~$22.80 AUD~~ Sale price $12.00 AUD Unit price per 1 Available Now Sale
Teeth 35	Pitch Circle Diameter (PD) 28.00 mm _{(1.102 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Outside Diameter (OD) 29.60 mm	Face Width (FW) 4.00 mm
Material: Acetal Locking Method: No Set Screw Quality: No Insert
Part Number: G028B-35-M08-040-060-A-P Spur Gears - 35 tooth - 28x6 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Mon, Jun 30, 2025 Regular price $12.05 AUD Regular price Sale price $12.05 AUD Unit price per Each
Teeth 35	Pitch Circle Diameter (PD) 28.00 mm _{(1.102 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Outside Diameter (OD) 29.60 mm
Material: Acetal Face Width (FW): 4.00 mm Locking Method: No Set Screw Quality: No Insert
Part Number: G028B-35-M08-040-060-A-P Spur Gears - 35 tooth - 28x6 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Mon, Jun 30, 2025 Regular price $12.05 AUD Regular price Sale price $12.05 AUD Unit price per Each View the product page first if you are unsure.
G028B-35-M08-040-060-A-P --- Spur Gears - 35 tooth - 28x6 mm - Acetal G028B-35-M08-040-060-A-P --- Spur Gears - 35 tooth - 28x6 mm - Acetal Regular price $12.05 AUD Regular price Sale price $12.05 AUD Unit price per Out of stock! Backorder Now
Teeth 36	Pitch Circle Diameter (PD) 29.80 mm _{(1.173 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Outside Diameter (OD) 31.40 mm	Face Width (FW) 4.00 mm
Material: Acetal Locking Method: No Set Screw Quality: No Insert
Part Number: G030B-36-M08-040-060-A-P Spur Gears - 36 tooth - 29.8x6 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Mon, Jun 30, 2025 Regular price $12.41 AUD Regular price Sale price $12.41 AUD Unit price per Each
Teeth 36	Pitch Circle Diameter (PD) 29.80 mm _{(1.173 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Outside Diameter (OD) 31.40 mm
Material: Acetal Face Width (FW): 4.00 mm Locking Method: No Set Screw Quality: No Insert
Part Number: G030B-36-M08-040-060-A-P Spur Gears - 36 tooth - 29.8x6 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Mon, Jun 30, 2025 Regular price $12.41 AUD Regular price Sale price $12.41 AUD Unit price per Each View the product page first if you are unsure.
G030B-36-M08-040-060-A-P --- Spur Gears - 36 tooth - 29.8x6 mm - Acetal G030B-36-M08-040-060-A-P --- Spur Gears - 36 tooth - 29.8x6 mm - Acetal Regular price $12.41 AUD Regular price Sale price $12.41 AUD Unit price per Out of stock! Backorder Now
Teeth 45	Pitch Circle Diameter (PD) 36.00 mm _{(1.417 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Outside Diameter (OD) 37.60 mm	Face Width (FW) 4.00 mm
Material: Acetal Locking Method: No Set Screw Quality: No Insert
Part Number: G036B-45-M08-040-060-A-P Spur Gears - 45 tooth - 36x6 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Mon, Jun 30, 2025 Regular price $14.23 AUD Regular price Sale price $14.23 AUD Unit price per Each
Teeth 45	Pitch Circle Diameter (PD) 36.00 mm _{(1.417 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Outside Diameter (OD) 37.60 mm
Material: Acetal Face Width (FW): 4.00 mm Locking Method: No Set Screw Quality: No Insert
Part Number: G036B-45-M08-040-060-A-P Spur Gears - 45 tooth - 36x6 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Mon, Jun 30, 2025 Regular price $14.23 AUD Regular price Sale price $14.23 AUD Unit price per Each View the product page first if you are unsure.
G036B-45-M08-040-060-A-P --- Spur Gears - 45 tooth - 36x6 mm - Acetal G036B-45-M08-040-060-A-P --- Spur Gears - 45 tooth - 36x6 mm - Acetal Regular price $14.23 AUD Regular price Sale price $14.23 AUD Unit price per Out of stock! Backorder Now
Teeth 48	Pitch Circle Diameter (PD) 38.40 mm _{(1.512 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Outside Diameter (OD) 40.00 mm	Face Width (FW) 4.00 mm
Material: Acetal Locking Method: No Set Screw Quality: No Insert
Part Number: G038B-48-M08-040-060-A-P Spur Gears - 48 tooth - 38.4x6 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Mon, Jun 30, 2025 Regular price $14.68 AUD Regular price Sale price $14.68 AUD Unit price per Each
Teeth 48	Pitch Circle Diameter (PD) 38.40 mm _{(1.512 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Outside Diameter (OD) 40.00 mm
Material: Acetal Face Width (FW): 4.00 mm Locking Method: No Set Screw Quality: No Insert
Part Number: G038B-48-M08-040-060-A-P Spur Gears - 48 tooth - 38.4x6 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Mon, Jun 30, 2025 Regular price $14.68 AUD Regular price Sale price $14.68 AUD Unit price per Each View the product page first if you are unsure.
G038B-48-M08-040-060-A-P --- Spur Gears - 48 tooth - 38.4x6 mm - Acetal G038B-48-M08-040-060-A-P --- Spur Gears - 48 tooth - 38.4x6 mm - Acetal Regular price $14.68 AUD Regular price Sale price $14.68 AUD Unit price per Out of stock! Backorder Now
Teeth 50	Pitch Circle Diameter (PD) 40.00 mm _{(1.575 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Outside Diameter (OD) 41.60 mm	Face Width (FW) 4.00 mm
Material: Acetal Locking Method: No Set Screw Quality: No Insert
Part Number: G040B-50-M08-040-060-A-P Spur Gears - 50 tooth - 40x6 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Mon, Jun 30, 2025 Regular price $15.05 AUD Regular price Sale price $15.05 AUD Unit price per Each
Teeth 50	Pitch Circle Diameter (PD) 40.00 mm _{(1.575 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Outside Diameter (OD) 41.60 mm
Material: Acetal Face Width (FW): 4.00 mm Locking Method: No Set Screw Quality: No Insert
Part Number: G040B-50-M08-040-060-A-P Spur Gears - 50 tooth - 40x6 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Mon, Jun 30, 2025 Regular price $15.05 AUD Regular price Sale price $15.05 AUD Unit price per Each View the product page first if you are unsure.
G040B-50-M08-040-060-A-P --- Spur Gears - 50 tooth - 40x6 mm - Acetal G040B-50-M08-040-060-A-P --- Spur Gears - 50 tooth - 40x6 mm - Acetal Regular price $15.05 AUD Regular price Sale price $15.05 AUD Unit price per Out of stock! Backorder Now
Teeth 56	Pitch Circle Diameter (PD) 44.80 mm _{(1.764 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Outside Diameter (OD) 46.40 mm	Face Width (FW) 4.00 mm
Material: Acetal Locking Method: No Set Screw Quality: No Insert
Part Number: G045B-56-M08-040-060-A-P Spur Gears - 56 tooth - 44.8x6 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Mon, Jun 30, 2025 Regular price $15.32 AUD Regular price Sale price $15.32 AUD Unit price per Each
Teeth 56	Pitch Circle Diameter (PD) 44.80 mm _{(1.764 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Outside Diameter (OD) 46.40 mm
Material: Acetal Face Width (FW): 4.00 mm Locking Method: No Set Screw Quality: No Insert
Part Number: G045B-56-M08-040-060-A-P Spur Gears - 56 tooth - 44.8x6 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Mon, Jun 30, 2025 Regular price $15.32 AUD Regular price Sale price $15.32 AUD Unit price per Each View the product page first if you are unsure.
G045B-56-M08-040-060-A-P --- Spur Gears - 56 tooth - 44.8x6 mm - Acetal G045B-56-M08-040-060-A-P --- Spur Gears - 56 tooth - 44.8x6 mm - Acetal Regular price $15.32 AUD Regular price Sale price $15.32 AUD Unit price per Out of stock! Backorder Now
Teeth 64	Pitch Circle Diameter (PD) 51.20 mm _{(2.016 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Outside Diameter (OD) 52.80 mm	Face Width (FW) 4.00 mm
Material: Acetal Locking Method: No Set Screw Quality: No Insert
Part Number: G051B-64-M08-040-060-A-P Spur Gears - 64 tooth - 51.2x6 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Mon, Jun 30, 2025 Regular price $17.23 AUD Regular price Sale price $17.23 AUD Unit price per Each
Teeth 64	Pitch Circle Diameter (PD) 51.20 mm _{(2.016 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Outside Diameter (OD) 52.80 mm
Material: Acetal Face Width (FW): 4.00 mm Locking Method: No Set Screw Quality: No Insert
Part Number: G051B-64-M08-040-060-A-P Spur Gears - 64 tooth - 51.2x6 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Mon, Jun 30, 2025 Regular price $17.23 AUD Regular price Sale price $17.23 AUD Unit price per Each View the product page first if you are unsure.
G051B-64-M08-040-060-A-P --- Spur Gears - 64 tooth - 51.2x6 mm - Acetal G051B-64-M08-040-060-A-P --- Spur Gears - 64 tooth - 51.2x6 mm - Acetal Regular price $17.23 AUD Regular price Sale price $17.23 AUD Unit price per Out of stock! Backorder Now
Teeth 70	Pitch Circle Diameter (PD) 56.00 mm _{(2.205 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Outside Diameter (OD) 57.60 mm	Face Width (FW) 4.00 mm
Material: Acetal Locking Method: No Set Screw Quality: No Insert
Part Number: G056B-70-M08-040-060-A-P Spur Gears - 70 tooth - 56x6 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Mon, Jun 30, 2025 Regular price $17.68 AUD Regular price Sale price $17.68 AUD Unit price per Each
Teeth 70	Pitch Circle Diameter (PD) 56.00 mm _{(2.205 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Outside Diameter (OD) 57.60 mm
Material: Acetal Face Width (FW): 4.00 mm Locking Method: No Set Screw Quality: No Insert
Part Number: G056B-70-M08-040-060-A-P Spur Gears - 70 tooth - 56x6 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Mon, Jun 30, 2025 Regular price $17.68 AUD Regular price Sale price $17.68 AUD Unit price per Each View the product page first if you are unsure.
G056B-70-M08-040-060-A-P --- Spur Gears - 70 tooth - 56x6 mm - Acetal G056B-70-M08-040-060-A-P --- Spur Gears - 70 tooth - 56x6 mm - Acetal Regular price $17.68 AUD Regular price Sale price $17.68 AUD Unit price per Out of stock! Backorder Now
Teeth 72	Pitch Circle Diameter (PD) 57.60 mm _{(2.268 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Outside Diameter (OD) 59.20 mm	Face Width (FW) 4.00 mm
Material: Acetal Locking Method: No Set Screw Quality: No Insert
Part Number: G058B-72-M08-040-060-A-P Spur Gears - 72 tooth - 57.6x6 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Mon, Jun 30, 2025 Regular price $18.59 AUD Regular price Sale price $18.59 AUD Unit price per Each
Teeth 72	Pitch Circle Diameter (PD) 57.60 mm _{(2.268 in.)}	Bore (d) 6.000 mm _{(0.236 in.)}	Outside Diameter (OD) 59.20 mm
Material: Acetal Face Width (FW): 4.00 mm Locking Method: No Set Screw Quality: No Insert
Part Number: G058B-72-M08-040-060-A-P Spur Gears - 72 tooth - 57.6x6 mm - Acetal Out of Stock \| Backorder Now \| Orders can be expected around Mon, Jun 30, 2025 Regular price $18.59 AUD Regular price Sale price $18.59 AUD Unit price per Each View the product page first if you are unsure.
G058B-72-M08-040-060-A-P --- Spur Gears - 72 tooth - 57.6x6 mm - Acetal G058B-72-M08-040-060-A-P --- Spur Gears - 72 tooth - 57.6x6 mm - Acetal Regular price $18.59 AUD Regular price Sale price $18.59 AUD Unit price per Out of stock! Backorder Now
