Gears - Spur - Standard - 6DP Steel

2 Products in this selection
  • PCD = No. of Teeth x 4.233mm (1/6 in.). 14.5 Degree Pressure Angle. Steel. DP stands for Diametrical Pitch and is an imperial measurement system.
  • The diameter increases by 1 inch for every 6 teeth
  • 6 Diametrical Pitch. Approx 13.3mm between the teeth.
Additional resources:
6DP Gear Racks
A more concise listing may be found on the Smallparts store at Gears - Spur - Standard - 6DP Steel. Smallparts promote the most popular MBA products.
Teeth Pitch Circle Diameter (PD) Bore (d) Outside Diameter (OD) Face Width (FW) Type Indicative
Teeth
12
Pitch Circle Diameter (PD)
50.800
mm

(2 in.)
Bore (d)
25.400
mm

(1 in.)
Outside Diameter (OD)
59.258
mm
Face Width (FW)
38.100
mm
Spur Gears - 12 tooth - 50.8x25.4 mm - Steel 0.20 carbon steel with no subsequent treatment
Material: Steel 0.20 carbon steel with no subsequent treatment    Hub Diameter (D1): 37.084 mm    Hub Projection (HL): 22.352 mm    Locking Method: None    Quality: Commercial
Part Number: G051B-12-V6-381-254-CG Spur Gears - 12 tooth - 50.8x25.4 mm - Steel 0.20 carbon steel with no subsequent treatment
Out of Stock | Backorder Now | Orders can be expected around Mon, Jun 02, 2025
$349.23 AUD
$349.23 AUD
Each
Teeth Pitch Circle Diameter (PD) Bore (d) Outside Diameter (OD) Indicative
Teeth
12
Pitch Circle Diameter (PD)
50.800
mm

(2 in.)
Bore (d)
25.400
mm

(1 in.)
Outside Diameter (OD)
59.258
mm
Spur Gears - 12 tooth - 50.8x25.4 mm - Steel 0.20 carbon steel with no subsequent treatment
Material: Steel 0.20 carbon steel with no subsequent treatment    Face Width (FW): 38.100 mm    Hub Diameter (D1): 37.084 mm    Hub Projection (HL): 22.352 mm    Locking Method: None    Quality: Commercial
Part Number: G051B-12-V6-381-254-CG Spur Gears - 12 tooth - 50.8x25.4 mm - Steel 0.20 carbon steel with no subsequent treatment
Out of Stock | Backorder Now | Orders can be expected around Mon, Jun 02, 2025
$349.23 AUD
$349.23 AUD
Each
View the product page first if you are unsure.
Teeth
24
Pitch Circle Diameter (PD)
101.600
mm

(4 in.)
Bore (d)
31.750
mm

(1.25 in.)
Outside Diameter (OD)
110.058
mm
Face Width (FW)
38.100
mm
Spur Gears - 24 tooth - 101.6x31.75 mm - Steel 0.20 carbon steel with no subsequent treatment
Material: Steel 0.20 carbon steel with no subsequent treatment    Hub Diameter (D1): 76.200 mm    Hub Projection (HL): 22.352 mm    Locking Method: None    Quality: Commercial
Part Number: G102B-24-V6-381-318-CG Spur Gears - 24 tooth - 101.6x31.75 mm - Steel 0.20 carbon steel with no subsequent treatment
Out of Stock | Backorder Now | Orders can be expected around Mon, Jun 02, 2025
$923.68 AUD
$923.68 AUD
Each
Teeth
24
Pitch Circle Diameter (PD)
101.600
mm

(4 in.)
Bore (d)
31.750
mm

(1.25 in.)
Outside Diameter (OD)
110.058
mm
Spur Gears - 24 tooth - 101.6x31.75 mm - Steel 0.20 carbon steel with no subsequent treatment
Material: Steel 0.20 carbon steel with no subsequent treatment    Face Width (FW): 38.100 mm    Hub Diameter (D1): 76.200 mm    Hub Projection (HL): 22.352 mm    Locking Method: None    Quality: Commercial
Part Number: G102B-24-V6-381-318-CG Spur Gears - 24 tooth - 101.6x31.75 mm - Steel 0.20 carbon steel with no subsequent treatment
Out of Stock | Backorder Now | Orders can be expected around Mon, Jun 02, 2025
$923.68 AUD
$923.68 AUD
Each
View the product page first if you are unsure.
