Gears - Spur - Hubless - 24DP

1 Item Available
This is a combined category of 24DP Hubless Spur Gears.
Use the filters in the table below, or the category tree above to refine the selection. To order any item, simply click the part number for a full product page, then add to your cart.
Additional resources:
A more concise listing may be found on the Smallparts store at Gears - Spur - Hubless - 24DP. Smallparts promote the most popular MBA products.
Teeth Pitch Circle Diameter (PD) Bore (d) Outside Diameter (OD) Face Width (FW) Type Indicative
Teeth
20
Pitch Circle Diameter (PD)
21.16
mm

(0.833 in.)
Bore (d)
6.350
mm

(0.25 in.)
Outside Diameter (OD)
23.266
mm
Face Width (FW)
6.35
mm
Type
Hubless
Spur Gears - 20 tooth - 21.16x6.35 mm - Carbon Steel
Material: Carbon Steel    Locking Method: None
Category: Gears - Spur - Hubless - 24DP - Steel
Part Number: G021B-20-V24-064-064-C-N Spur Gears - 20 tooth - 21.16x6.35 mm - Carbon Steel
2 Available Immediately | Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity
$22.00 AUD
$41.80 AUD $22.00 AUD
Each
Teeth Pitch Circle Diameter (PD) Bore (d) Outside Diameter (OD) Indicative
Teeth
20
Pitch Circle Diameter (PD)
21.16
mm

(0.833 in.)
Bore (d)
6.350
mm

(0.25 in.)
Outside Diameter (OD)
23.266
mm
Spur Gears - 20 tooth - 21.16x6.35 mm - Carbon Steel
Material: Carbon Steel    Face Width (FW): 6.35 mm    Type: Hubless    Locking Method: None
Category: Gears - Spur - Hubless - 24DP - Steel
Part Number: G021B-20-V24-064-064-C-N Spur Gears - 20 tooth - 21.16x6.35 mm - Carbon Steel
2 Available Immediately | Item Discontinued - Only the quantity available may be ordered - Please contact us if you need a larger quantity
$22.00 AUD
$41.80 AUD $22.00 AUD
Each
