Collection: Inserts - Rivet Nuts

Inserts (With Images)

Rivet Nuts

Klik

32 Products in this selection

This is a combined category of Rivet Nuts Inserts.
Use the filters in the table below, or the category tree above to refine the selection. To order any item, simply click the part number for a full product page, then add to your cart.

Inserts - Rivet Nuts

Additional resources:

A more concise listing may be found on the Smallparts store at Inserts - Rivet Nuts. Smallparts promote the most popular MBA products.

Internal Thread	Drill Hole Size	Grip Range	Body Diameter (D)	Flange Diameter (F)	L	Indicative Image
Internal Thread 6-32 UNC (3.5mm)	Drill Hole Size 5.46 mm _{(0.215 in.)}	Grip Range 9.52 mm _{(0.375 in.)}
Material: Steel - Cadmium Finish Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-035C-064-TS Rivet Nuts Inserts - 6-32 UNC -3.5mm- 5.46x9.52 mm - Steel - Cadmium Finish Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $1.77 AUD Regular price Sale price $1.77 AUD Unit price per Each
Internal Thread	Drill Hole Size	Grip Range	Body Diameter (D)	Indicative Image
Internal Thread 6-32 UNC (3.5mm)	Drill Hole Size 5.46 mm _{(0.215 in.)}	Grip Range 9.52 mm _{(0.375 in.)}
Material: Steel - Cadmium Finish Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-035C-064-TS Rivet Nuts Inserts - 6-32 UNC -3.5mm- 5.46x9.52 mm - Steel - Cadmium Finish Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $1.77 AUD Regular price Sale price $1.77 AUD Unit price per Each View the product page first if you are unsure.
IN-RIV-035C-064-TS --- Rivet Nuts Inserts - 6-32 UNC -3.5mm- 5.46x9.52 mm - Steel - Cadmium Finish IN-RIV-035C-064-TS --- Rivet Nuts Inserts - 6-32 UNC -3.5mm- 5.46x9.52 mm - Steel - Cadmium Finish Regular price $1.77 AUD Regular price Sale price $1.77 AUD Unit price per Out of stock! Backorder Now
Internal Thread 6-32 UNC (3.5mm)	Drill Hole Size 6.75 mm _{(0.266 in.)}	Grip Range 0.50 - 2.83 mm _{(0.02 in.)}	Body Diameter (D) 6.73 mm	Flange Diameter (F) 9.52 mm	L 10.998 mm
M: 6.985 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-035C-028-R Rivet Nuts Inserts - 6-32 UNC -3.5mm- 6.75 - 0.50 - 2.83 10 Available Immediately \| Further orders can be expected around Wed, Jun 04, 2025 Regular price $0.86 AUD Regular price Sale price $0.86 AUD Unit price per Each
Internal Thread 6-32 UNC (3.5mm)	Drill Hole Size 6.75 mm _{(0.266 in.)}	Grip Range 0.50 - 2.83 mm _{(0.02 in.)}	Body Diameter (D) 6.73 mm
Flange Diameter (F): 9.52 mm L: 10.998 mm M: 6.985 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-035C-028-R Rivet Nuts Inserts - 6-32 UNC -3.5mm- 6.75 - 0.50 - 2.83 10 Available Immediately \| Further orders can be expected around Wed, Jun 04, 2025 Regular price $0.86 AUD Regular price Sale price $0.86 AUD Unit price per Each View the product page first if you are unsure.
IN-RIV-035C-028-R --- Rivet Nuts Inserts - 6-32 UNC -3.5mm- 6.75 - 0.50 - 2.83 IN-RIV-035C-028-R --- Rivet Nuts Inserts - 6-32 UNC -3.5mm- 6.75 - 0.50 - 2.83 Regular price $0.86 AUD Regular price Sale price $0.86 AUD Unit price per 10 Available Now
Internal Thread 6-32 UNC (3.5mm)	Drill Hole Size 6.75 mm _{(0.266 in.)}	Grip Range 2.03 - 3.32 mm _{(0.08 in.)}	Body Diameter (D) 6.73 mm	Flange Diameter (F) 9.52 mm	L 12.294 mm
M: 6.985 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-035C-033-R Rivet Nuts Inserts - 6-32 UNC -3.5mm- 6.75 - 2.03 - 3.32 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $0.77 AUD Regular price Sale price $0.77 AUD Unit price per Each
Internal Thread 6-32 UNC (3.5mm)	Drill Hole Size 6.75 mm _{(0.266 in.)}	Grip Range 2.03 - 3.32 mm _{(0.08 in.)}	Body Diameter (D) 6.73 mm
Flange Diameter (F): 9.52 mm L: 12.294 mm M: 6.985 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-035C-033-R Rivet Nuts Inserts - 6-32 UNC -3.5mm- 6.75 - 2.03 - 3.32 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $0.77 AUD Regular price Sale price $0.77 AUD Unit price per Each View the product page first if you are unsure.
IN-RIV-035C-033-R --- Rivet Nuts Inserts - 6-32 UNC -3.5mm- 6.75 - 2.03 - 3.32 IN-RIV-035C-033-R --- Rivet Nuts Inserts - 6-32 UNC -3.5mm- 6.75 - 2.03 - 3.32 Regular price $0.77 AUD Regular price Sale price $0.77 AUD Unit price per Out of stock! Backorder Now
Internal Thread M4 (4x0.7mm)	Drill Hole Size 6.8 mm _{(0.268 in.)}	Grip Range 0.50 - 2.00 mm _{(0.02 in.)}	Body Diameter (D) 6.75 mm	Flange Diameter (F) 9.5 mm	L 10.900 mm
M: 7.000 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-040-020-R (10 Pcs) Rivet Nuts Inserts - M4 -4x0.7mm- 6.8 - 0.50 - 2.00 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $0.59 AUD Regular price Sale price $0.59 AUD Unit price per Each
Internal Thread M4 (4x0.7mm)	Drill Hole Size 6.8 mm _{(0.268 in.)}	Grip Range 0.50 - 2.00 mm _{(0.02 in.)}	Body Diameter (D) 6.75 mm
Flange Diameter (F): 9.5 mm L: 10.900 mm M: 7.000 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-040-020-R (10 Pcs) Rivet Nuts Inserts - M4 -4x0.7mm- 6.8 - 0.50 - 2.00 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $0.59 AUD Regular price Sale price $0.59 AUD Unit price per Each View the product page first if you are unsure.
IN-RIV-040-020-R (10 Pcs) --- Rivet Nuts Inserts - M4 -4x0.7mm- 6.8 - 0.50 - 2.00 IN-RIV-040-020-R (10 Pcs) --- Rivet Nuts Inserts - M4 -4x0.7mm- 6.8 - 0.50 - 2.00 Regular price $0.59 AUD Regular price Sale price $0.59 AUD Unit price per Out of stock! Backorder Now
Internal Thread 8-32 UNC (4.17mm)	Drill Hole Size 5.61 mm _{(0.221 in.)}	Grip Range 1.90 - 3.55 mm _{(0.075 in.)}	Body Diameter (D) 5.61 mm	Flange Diameter (F) 9.07 mm	L 12.700 mm
M: 0.813 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-042C-036 Rivet Nuts Inserts - 8-32 UNC -4.17mm- 5.61 - 1.90 - 3.55 5 Available Immediately \| Further orders can be expected around Wed, Jun 04, 2025 Regular price $36.95 AUD Regular price Sale price $36.95 AUD Unit price per Each
Internal Thread 8-32 UNC (4.17mm)	Drill Hole Size 5.61 mm _{(0.221 in.)}	Grip Range 1.90 - 3.55 mm _{(0.075 in.)}	Body Diameter (D) 5.61 mm
Flange Diameter (F): 9.07 mm L: 12.700 mm M: 0.813 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-042C-036 Rivet Nuts Inserts - 8-32 UNC -4.17mm- 5.61 - 1.90 - 3.55 5 Available Immediately \| Further orders can be expected around Wed, Jun 04, 2025 Regular price $36.95 AUD Regular price Sale price $36.95 AUD Unit price per Each View the product page first if you are unsure.
IN-RIV-042C-036 --- Rivet Nuts Inserts - 8-32 UNC -4.17mm- 5.61 - 1.90 - 3.55 IN-RIV-042C-036 --- Rivet Nuts Inserts - 8-32 UNC -4.17mm- 5.61 - 1.90 - 3.55 Regular price $36.95 AUD Regular price Sale price $36.95 AUD Unit price per 5 Available Now
Internal Thread 8-32 UNC (4.17mm)	Drill Hole Size 6.25 mm _{(0.246 in.)}	Grip Range 9.52 mm _{(0.375 in.)}
Material: Steel - Cadmium Finish Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-042C-072-TS Rivet Nuts Inserts - 8-32 UNC -4.17mm- 6.25x9.52 mm - Steel - Cadmium Finish Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $1.05 AUD Regular price Sale price $1.05 AUD Unit price per Each
Internal Thread 8-32 UNC (4.17mm)	Drill Hole Size 6.25 mm _{(0.246 in.)}	Grip Range 9.52 mm _{(0.375 in.)}
Material: Steel - Cadmium Finish Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-042C-072-TS Rivet Nuts Inserts - 8-32 UNC -4.17mm- 6.25x9.52 mm - Steel - Cadmium Finish Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $1.05 AUD Regular price Sale price $1.05 AUD Unit price per Each View the product page first if you are unsure.
IN-RIV-042C-072-TS --- Rivet Nuts Inserts - 8-32 UNC -4.17mm- 6.25x9.52 mm - Steel - Cadmium Finish IN-RIV-042C-072-TS --- Rivet Nuts Inserts - 8-32 UNC -4.17mm- 6.25x9.52 mm - Steel - Cadmium Finish Regular price $1.05 AUD Regular price Sale price $1.05 AUD Unit price per Out of stock! Backorder Now
Internal Thread 8-32 UNC (4.17mm)	Drill Hole Size 6.75 mm _{(0.266 in.)}	Grip Range 0.50 - 2.83 mm _{(0.02 in.)}	Body Diameter (D) 6.73 mm	Flange Diameter (F) 9.52 mm	L 10.998 mm
M: 6.985 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-042C-028-R Rivet Nuts Inserts - 8-32 UNC -4.17mm- 6.75 - 0.50 - 2.83 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $1.32 AUD Regular price Sale price $1.32 AUD Unit price per Each
Internal Thread 8-32 UNC (4.17mm)	Drill Hole Size 6.75 mm _{(0.266 in.)}	Grip Range 0.50 - 2.83 mm _{(0.02 in.)}	Body Diameter (D) 6.73 mm
Flange Diameter (F): 9.52 mm L: 10.998 mm M: 6.985 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-042C-028-R Rivet Nuts Inserts - 8-32 UNC -4.17mm- 6.75 - 0.50 - 2.83 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $1.32 AUD Regular price Sale price $1.32 AUD Unit price per Each View the product page first if you are unsure.
IN-RIV-042C-028-R --- Rivet Nuts Inserts - 8-32 UNC -4.17mm- 6.75 - 0.50 - 2.83 IN-RIV-042C-028-R --- Rivet Nuts Inserts - 8-32 UNC -4.17mm- 6.75 - 0.50 - 2.83 Regular price $1.32 AUD Regular price Sale price $1.32 AUD Unit price per Out of stock! Backorder Now
Internal Thread 8-32 UNC (4.17mm)	Drill Hole Size 6.75 mm _{(0.266 in.)}	Grip Range 2.03 - 3.32 mm _{(0.08 in.)}	Body Diameter (D) 6.73 mm	Flange Diameter (F) 9.52 mm	L 12.294 mm
M: 6.985 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-042C-033-R Rivet Nuts Inserts - 8-32 UNC -4.17mm- 6.75 - 2.03 - 3.32 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $1.50 AUD Regular price Sale price $1.50 AUD Unit price per Each
Internal Thread 8-32 UNC (4.17mm)	Drill Hole Size 6.75 mm _{(0.266 in.)}	Grip Range 2.03 - 3.32 mm _{(0.08 in.)}	Body Diameter (D) 6.73 mm
Flange Diameter (F): 9.52 mm L: 12.294 mm M: 6.985 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-042C-033-R Rivet Nuts Inserts - 8-32 UNC -4.17mm- 6.75 - 2.03 - 3.32 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $1.50 AUD Regular price Sale price $1.50 AUD Unit price per Each View the product page first if you are unsure.
IN-RIV-042C-033-R --- Rivet Nuts Inserts - 8-32 UNC -4.17mm- 6.75 - 2.03 - 3.32 IN-RIV-042C-033-R --- Rivet Nuts Inserts - 8-32 UNC -4.17mm- 6.75 - 2.03 - 3.32 Regular price $1.50 AUD Regular price Sale price $1.50 AUD Unit price per Out of stock! Backorder Now
Internal Thread 10-24 UNC (4.76mm)	Drill Hole Size 7.04 mm _{(0.277 in.)}	Grip Range 9.52 mm _{(0.375 in.)}
Material: Steel - Cadmium Finish Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-048C-080-TS Rivet Nuts Inserts - 10-24 UNC -4.76mm- 7.04x9.52 mm - Steel - Cadmium Finish Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $1.77 AUD Regular price Sale price $1.77 AUD Unit price per Each
Internal Thread 10-24 UNC (4.76mm)	Drill Hole Size 7.04 mm _{(0.277 in.)}	Grip Range 9.52 mm _{(0.375 in.)}
Material: Steel - Cadmium Finish Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-048C-080-TS Rivet Nuts Inserts - 10-24 UNC -4.76mm- 7.04x9.52 mm - Steel - Cadmium Finish Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $1.77 AUD Regular price Sale price $1.77 AUD Unit price per Each View the product page first if you are unsure.
IN-RIV-048C-080-TS --- Rivet Nuts Inserts - 10-24 UNC -4.76mm- 7.04x9.52 mm - Steel - Cadmium Finish IN-RIV-048C-080-TS --- Rivet Nuts Inserts - 10-24 UNC -4.76mm- 7.04x9.52 mm - Steel - Cadmium Finish Regular price $1.77 AUD Regular price Sale price $1.77 AUD Unit price per Out of stock! Backorder Now
Internal Thread 10-24 UNC (4.76mm)	Drill Hole Size 7.54 mm _{(0.297 in.)}	Grip Range 0.50 - 3.38 mm _{(0.02 in.)}	Body Diameter (D) 7.52 mm	Flange Diameter (F) 10.16 mm	L 12.395 mm
M: 7.620 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-048C-034-R Rivet Nuts Inserts - 10-24 UNC -4.76mm- 7.54 - 0.50 - 3.38 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $0.68 AUD Regular price Sale price $0.68 AUD Unit price per Each
Internal Thread 10-24 UNC (4.76mm)	Drill Hole Size 7.54 mm _{(0.297 in.)}	Grip Range 0.50 - 3.38 mm _{(0.02 in.)}	Body Diameter (D) 7.52 mm
Flange Diameter (F): 10.16 mm L: 12.395 mm M: 7.620 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-048C-034-R Rivet Nuts Inserts - 10-24 UNC -4.76mm- 7.54 - 0.50 - 3.38 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $0.68 AUD Regular price Sale price $0.68 AUD Unit price per Each View the product page first if you are unsure.
IN-RIV-048C-034-R --- Rivet Nuts Inserts - 10-24 UNC -4.76mm- 7.54 - 0.50 - 3.38 IN-RIV-048C-034-R --- Rivet Nuts Inserts - 10-24 UNC -4.76mm- 7.54 - 0.50 - 3.38 Regular price $0.68 AUD Regular price Sale price $0.68 AUD Unit price per Out of stock! Backorder Now
Internal Thread 10-24 UNC (4.76mm)	Drill Hole Size 7.54 mm _{(0.297 in.)}	Grip Range 3.30 - 5.72 mm _{(0.13 in.)}	Body Diameter (D) 7.52 mm	Flange Diameter (F) 10.16 mm	L 15.088 mm
M: 7.620 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-048C-057-R (5 Pcs) Rivet Nuts Inserts - 10-24 UNC -4.76mm- 7.54 - 3.30 - 5.72 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $1.50 AUD Regular price Sale price $1.50 AUD Unit price per Each
Internal Thread 10-24 UNC (4.76mm)	Drill Hole Size 7.54 mm _{(0.297 in.)}	Grip Range 3.30 - 5.72 mm _{(0.13 in.)}	Body Diameter (D) 7.52 mm
Flange Diameter (F): 10.16 mm L: 15.088 mm M: 7.620 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-048C-057-R (5 Pcs) Rivet Nuts Inserts - 10-24 UNC -4.76mm- 7.54 - 3.30 - 5.72 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $1.50 AUD Regular price Sale price $1.50 AUD Unit price per Each View the product page first if you are unsure.
IN-RIV-048C-057-R (5 Pcs) --- Rivet Nuts Inserts - 10-24 UNC -4.76mm- 7.54 - 3.30 - 5.72 IN-RIV-048C-057-R (5 Pcs) --- Rivet Nuts Inserts - 10-24 UNC -4.76mm- 7.54 - 3.30 - 5.72 Regular price $1.50 AUD Regular price Sale price $1.50 AUD Unit price per Out of stock! Backorder Now
Internal Thread 10-32 UNF (4.76mm)	Drill Hole Size 6.35 mm _{(0.25 in.)}	Grip Range 0.25 - 2.03 mm _{(0.01 in.)}	Body Diameter (D) 6.35 mm	Flange Diameter (F) 10.31 mm	L 13.487 mm
M: 0.965 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-048F-020 Rivet Nuts Inserts - 10-32 UNF -4.76mm- 6.35 - 0.25 - 2.03 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $19.77 AUD Regular price Sale price $19.77 AUD Unit price per Each
Internal Thread 10-32 UNF (4.76mm)	Drill Hole Size 6.35 mm _{(0.25 in.)}	Grip Range 0.25 - 2.03 mm _{(0.01 in.)}	Body Diameter (D) 6.35 mm
Flange Diameter (F): 10.31 mm L: 13.487 mm M: 0.965 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-048F-020 Rivet Nuts Inserts - 10-32 UNF -4.76mm- 6.35 - 0.25 - 2.03 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $19.77 AUD Regular price Sale price $19.77 AUD Unit price per Each View the product page first if you are unsure.
IN-RIV-048F-020 --- Rivet Nuts Inserts - 10-32 UNF -4.76mm- 6.35 - 0.25 - 2.03 IN-RIV-048F-020 --- Rivet Nuts Inserts - 10-32 UNF -4.76mm- 6.35 - 0.25 - 2.03 Regular price $19.77 AUD Regular price Sale price $19.77 AUD Unit price per Out of stock! Backorder Now
Internal Thread 10-32 UNF (4.76mm)	Drill Hole Size 6.35 mm _{(0.25 in.)}	Grip Range 2.03 - 3.32 mm _{(0.08 in.)}	Body Diameter (D) 6.35 mm	Flange Diameter (F) 10.31 mm	L 15.088 mm
M: 0.965 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-048F-033 Rivet Nuts Inserts - 10-32 UNF -4.76mm- 6.35 - 2.03 - 3.32 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $13.32 AUD Regular price Sale price $13.32 AUD Unit price per Each
Internal Thread 10-32 UNF (4.76mm)	Drill Hole Size 6.35 mm _{(0.25 in.)}	Grip Range 2.03 - 3.32 mm _{(0.08 in.)}	Body Diameter (D) 6.35 mm
Flange Diameter (F): 10.31 mm L: 15.088 mm M: 0.965 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-048F-033 Rivet Nuts Inserts - 10-32 UNF -4.76mm- 6.35 - 2.03 - 3.32 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $13.32 AUD Regular price Sale price $13.32 AUD Unit price per Each View the product page first if you are unsure.
IN-RIV-048F-033 --- Rivet Nuts Inserts - 10-32 UNF -4.76mm- 6.35 - 2.03 - 3.32 IN-RIV-048F-033 --- Rivet Nuts Inserts - 10-32 UNF -4.76mm- 6.35 - 2.03 - 3.32 Regular price $13.32 AUD Regular price Sale price $13.32 AUD Unit price per Out of stock! Backorder Now
Internal Thread 10-32 UNF (4.76mm)	Drill Hole Size 7.04 mm _{(0.277 in.)}	Grip Range 9.52 mm _{(0.375 in.)}
Material: Steel - Cadmium Finish Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-048F-080-TS (50 Pcs) Rivet Nuts Inserts - 10-32 UNF -4.76mm- 7.04x9.52 mm - Steel - Cadmium Finish Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $159.05 AUD Regular price Sale price $159.05 AUD Unit price per Per 100
Internal Thread 10-32 UNF (4.76mm)	Drill Hole Size 7.04 mm _{(0.277 in.)}	Grip Range 9.52 mm _{(0.375 in.)}
Material: Steel - Cadmium Finish Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-048F-080-TS (50 Pcs) Rivet Nuts Inserts - 10-32 UNF -4.76mm- 7.04x9.52 mm - Steel - Cadmium Finish Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $159.05 AUD Regular price Sale price $159.05 AUD Unit price per Per 100 View the product page first if you are unsure.
IN-RIV-048F-080-TS (50 Pcs) --- Rivet Nuts Inserts - 10-32 UNF -4.76mm- 7.04x9.52 mm - Steel - Cadmium Finish IN-RIV-048F-080-TS (50 Pcs) --- Rivet Nuts Inserts - 10-32 UNF -4.76mm- 7.04x9.52 mm - Steel - Cadmium Finish Regular price $159.05 AUD Regular price Sale price $159.05 AUD Unit price per Out of stock! Backorder Now
Internal Thread 10-32 UNF (4.76mm)	Drill Hole Size 7.54 mm _{(0.297 in.)}	Grip Range 0.50 - 3.38 mm _{(0.02 in.)}	Body Diameter (D) 7.52 mm	Flange Diameter (F) 10.16 mm	L 12.395 mm
M: 7.620 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-048F-034-R (10 Pcs) Rivet Nuts Inserts - 10-32 UNF -4.76mm- 7.54 - 0.50 - 3.38 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $0.68 AUD Regular price Sale price $0.68 AUD Unit price per Each
Internal Thread 10-32 UNF (4.76mm)	Drill Hole Size 7.54 mm _{(0.297 in.)}	Grip Range 0.50 - 3.38 mm _{(0.02 in.)}	Body Diameter (D) 7.52 mm
Flange Diameter (F): 10.16 mm L: 12.395 mm M: 7.620 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-048F-034-R (10 Pcs) Rivet Nuts Inserts - 10-32 UNF -4.76mm- 7.54 - 0.50 - 3.38 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $0.68 AUD Regular price Sale price $0.68 AUD Unit price per Each View the product page first if you are unsure.
IN-RIV-048F-034-R (10 Pcs) --- Rivet Nuts Inserts - 10-32 UNF -4.76mm- 7.54 - 0.50 - 3.38 IN-RIV-048F-034-R (10 Pcs) --- Rivet Nuts Inserts - 10-32 UNF -4.76mm- 7.54 - 0.50 - 3.38 Regular price $0.68 AUD Regular price Sale price $0.68 AUD Unit price per Out of stock! Backorder Now
Internal Thread 10-32 UNF (4.76mm)	Drill Hole Size 7.54 mm _{(0.297 in.)}	Grip Range 3.30 - 5.72 mm _{(0.13 in.)}	Body Diameter (D) 7.52 mm	Flange Diameter (F) 10.16 mm	L 15.088 mm
M: 7.620 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-048F-057-R Rivet Nuts Inserts - 10-32 UNF -4.76mm- 7.54 - 3.30 - 5.72 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $1.68 AUD Regular price Sale price $1.68 AUD Unit price per Each
Internal Thread 10-32 UNF (4.76mm)	Drill Hole Size 7.54 mm _{(0.297 in.)}	Grip Range 3.30 - 5.72 mm _{(0.13 in.)}	Body Diameter (D) 7.52 mm
Flange Diameter (F): 10.16 mm L: 15.088 mm M: 7.620 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-048F-057-R Rivet Nuts Inserts - 10-32 UNF -4.76mm- 7.54 - 3.30 - 5.72 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $1.68 AUD Regular price Sale price $1.68 AUD Unit price per Each View the product page first if you are unsure.
IN-RIV-048F-057-R --- Rivet Nuts Inserts - 10-32 UNF -4.76mm- 7.54 - 3.30 - 5.72 IN-RIV-048F-057-R --- Rivet Nuts Inserts - 10-32 UNF -4.76mm- 7.54 - 3.30 - 5.72 Regular price $1.68 AUD Regular price Sale price $1.68 AUD Unit price per Out of stock! Backorder Now
Internal Thread M5 (5x0.8mm)	Drill Hole Size 7.6 mm _{(0.299 in.)}	Grip Range 0.50 - 3.30 mm _{(0.02 in.)}	Body Diameter (D) 7.55 mm	Flange Diameter (F) 10.1 mm	L 12.300 mm
M: 7.600 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-050-033-R Rivet Nuts Inserts - M5 -5x0.8mm- 7.6 - 0.50 - 3.30 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $1.41 AUD Regular price Sale price $1.41 AUD Unit price per Each
Internal Thread M5 (5x0.8mm)	Drill Hole Size 7.6 mm _{(0.299 in.)}	Grip Range 0.50 - 3.30 mm _{(0.02 in.)}	Body Diameter (D) 7.55 mm
Flange Diameter (F): 10.1 mm L: 12.300 mm M: 7.600 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-050-033-R Rivet Nuts Inserts - M5 -5x0.8mm- 7.6 - 0.50 - 3.30 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $1.41 AUD Regular price Sale price $1.41 AUD Unit price per Each View the product page first if you are unsure.
IN-RIV-050-033-R --- Rivet Nuts Inserts - M5 -5x0.8mm- 7.6 - 0.50 - 3.30 IN-RIV-050-033-R --- Rivet Nuts Inserts - M5 -5x0.8mm- 7.6 - 0.50 - 3.30 Regular price $1.41 AUD Regular price Sale price $1.41 AUD Unit price per Out of stock! Backorder Now
Internal Thread M5 (5x0.8mm)	Drill Hole Size 7.6 mm _{(0.299 in.)}	Grip Range 3.30 - 5.70 mm _{(0.13 in.)}	Body Diameter (D) 7.55 mm	Flange Diameter (F) 10.1 mm	L 15.000 mm
M: 7.600 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-050-057-R Rivet Nuts Inserts - M5 -5x0.8mm- 7.6 - 3.30 - 5.70 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $0.77 AUD Regular price Sale price $0.77 AUD Unit price per Each
Internal Thread M5 (5x0.8mm)	Drill Hole Size 7.6 mm _{(0.299 in.)}	Grip Range 3.30 - 5.70 mm _{(0.13 in.)}	Body Diameter (D) 7.55 mm
Flange Diameter (F): 10.1 mm L: 15.000 mm M: 7.600 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-050-057-R Rivet Nuts Inserts - M5 -5x0.8mm- 7.6 - 3.30 - 5.70 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $0.77 AUD Regular price Sale price $0.77 AUD Unit price per Each View the product page first if you are unsure.
IN-RIV-050-057-R --- Rivet Nuts Inserts - M5 -5x0.8mm- 7.6 - 3.30 - 5.70 IN-RIV-050-057-R --- Rivet Nuts Inserts - M5 -5x0.8mm- 7.6 - 3.30 - 5.70 Regular price $0.77 AUD Regular price Sale price $0.77 AUD Unit price per Out of stock! Backorder Now
Internal Thread M6 (6x1mm)	Drill Hole Size 10 mm _{(0.394 in.)}	Grip Range 0.70 - 4.20 mm _{(0.028 in.)}	Body Diameter (D) 9.9 mm	Flange Diameter (F) 12.7 mm	L 14.900 mm
M: 9.000 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-060-042-R (5 Pcs) Rivet Nuts Inserts - M6 -6x1mm- 10 - 0.70 - 4.20 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $8.68 AUD Regular price Sale price $8.68 AUD Unit price per Per 5
Internal Thread M6 (6x1mm)	Drill Hole Size 10 mm _{(0.394 in.)}	Grip Range 0.70 - 4.20 mm _{(0.028 in.)}	Body Diameter (D) 9.9 mm
Flange Diameter (F): 12.7 mm L: 14.900 mm M: 9.000 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-060-042-R (5 Pcs) Rivet Nuts Inserts - M6 -6x1mm- 10 - 0.70 - 4.20 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $8.68 AUD Regular price Sale price $8.68 AUD Unit price per Per 5 View the product page first if you are unsure.
IN-RIV-060-042-R (5 Pcs) --- Rivet Nuts Inserts - M6 -6x1mm- 10 - 0.70 - 4.20 IN-RIV-060-042-R (5 Pcs) --- Rivet Nuts Inserts - M6 -6x1mm- 10 - 0.70 - 4.20 Regular price $8.68 AUD Regular price Sale price $8.68 AUD Unit price per Out of stock! Backorder Now
Internal Thread 1/4-20 UNC (6.35mm)	Drill Hole Size 8.43 mm _{(0.332 in.)}	Grip Range 0.50 - 2.83 mm _{(0.02 in.)}	Body Diameter (D) 8.43 mm	Flange Diameter (F) 12.06 mm	L 15.900 mm
M: 1.473 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-064C-028 (5 Pcs) Rivet Nuts Inserts - 1/4-20 UNC -6.35mm- 8.43 - 0.50 - 2.83 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $15.14 AUD Regular price Sale price $15.14 AUD Unit price per Per 5
Internal Thread 1/4-20 UNC (6.35mm)	Drill Hole Size 8.43 mm _{(0.332 in.)}	Grip Range 0.50 - 2.83 mm _{(0.02 in.)}	Body Diameter (D) 8.43 mm
Flange Diameter (F): 12.06 mm L: 15.900 mm M: 1.473 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-064C-028 (5 Pcs) Rivet Nuts Inserts - 1/4-20 UNC -6.35mm- 8.43 - 0.50 - 2.83 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $15.14 AUD Regular price Sale price $15.14 AUD Unit price per Per 5 View the product page first if you are unsure.
IN-RIV-064C-028 (5 Pcs) --- Rivet Nuts Inserts - 1/4-20 UNC -6.35mm- 8.43 - 0.50 - 2.83 IN-RIV-064C-028 (5 Pcs) --- Rivet Nuts Inserts - 1/4-20 UNC -6.35mm- 8.43 - 0.50 - 2.83 Regular price $15.14 AUD Regular price Sale price $15.14 AUD Unit price per Out of stock! Backorder Now
Internal Thread 1/4-20 UNC (6.35mm)	Drill Hole Size 8.43 mm _{(0.332 in.)}	Grip Range 2.03 - 3.56 mm _{(0.08 in.)}	Body Diameter (D) 8.43 mm	Flange Diameter (F) 12.06 mm	L 17.450 mm
M: 1.473 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-064C-036 Rivet Nuts Inserts - 1/4-20 UNC -6.35mm- 8.43 - 2.03 - 3.56 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $21.23 AUD Regular price Sale price $21.23 AUD Unit price per Each
Internal Thread 1/4-20 UNC (6.35mm)	Drill Hole Size 8.43 mm _{(0.332 in.)}	Grip Range 2.03 - 3.56 mm _{(0.08 in.)}	Body Diameter (D) 8.43 mm
Flange Diameter (F): 12.06 mm L: 17.450 mm M: 1.473 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-064C-036 Rivet Nuts Inserts - 1/4-20 UNC -6.35mm- 8.43 - 2.03 - 3.56 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $21.23 AUD Regular price Sale price $21.23 AUD Unit price per Each View the product page first if you are unsure.
IN-RIV-064C-036 --- Rivet Nuts Inserts - 1/4-20 UNC -6.35mm- 8.43 - 2.03 - 3.56 IN-RIV-064C-036 --- Rivet Nuts Inserts - 1/4-20 UNC -6.35mm- 8.43 - 2.03 - 3.56 Regular price $21.23 AUD Regular price Sale price $21.23 AUD Unit price per Out of stock! Backorder Now
Internal Thread 1/4-20 UNC (6.35mm)	Drill Hole Size 9.92 mm _{(0.391 in.)}	Grip Range 0.69 - 4.19 mm _{(0.027 in.)}	Body Diameter (D) 9.91 mm	Flange Diameter (F) 12.7 mm	L 14.986 mm
M: 9.017 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-064C-042-R (5 Pcs) Rivet Nuts Inserts - 1/4-20 UNC -6.35mm- 9.92 - 0.69 - 4.19 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $1.77 AUD Regular price Sale price $1.77 AUD Unit price per Each
Internal Thread 1/4-20 UNC (6.35mm)	Drill Hole Size 9.92 mm _{(0.391 in.)}	Grip Range 0.69 - 4.19 mm _{(0.027 in.)}	Body Diameter (D) 9.91 mm
Flange Diameter (F): 12.7 mm L: 14.986 mm M: 9.017 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-064C-042-R (5 Pcs) Rivet Nuts Inserts - 1/4-20 UNC -6.35mm- 9.92 - 0.69 - 4.19 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $1.77 AUD Regular price Sale price $1.77 AUD Unit price per Each View the product page first if you are unsure.
IN-RIV-064C-042-R (5 Pcs) --- Rivet Nuts Inserts - 1/4-20 UNC -6.35mm- 9.92 - 0.69 - 4.19 IN-RIV-064C-042-R (5 Pcs) --- Rivet Nuts Inserts - 1/4-20 UNC -6.35mm- 9.92 - 0.69 - 4.19 Regular price $1.77 AUD Regular price Sale price $1.77 AUD Unit price per Out of stock! Backorder Now
Internal Thread 1/4-20 UNC (6.35mm)	Drill Hole Size 9.92 mm _{(0.391 in.)}	Grip Range 4.19 - 6.61 mm _{(0.165 in.)}	Body Diameter (D) 9.91 mm	Flange Diameter (F) 12.7 mm	L 17.577 mm
M: 9.017 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-064C-066-R (5 Pcs) Rivet Nuts Inserts - 1/4-20 UNC -6.35mm- 9.92 - 4.19 - 6.61 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $0.95 AUD Regular price Sale price $0.95 AUD Unit price per Each
Internal Thread 1/4-20 UNC (6.35mm)	Drill Hole Size 9.92 mm _{(0.391 in.)}	Grip Range 4.19 - 6.61 mm _{(0.165 in.)}	Body Diameter (D) 9.91 mm
Flange Diameter (F): 12.7 mm L: 17.577 mm M: 9.017 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-064C-066-R (5 Pcs) Rivet Nuts Inserts - 1/4-20 UNC -6.35mm- 9.92 - 4.19 - 6.61 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $0.95 AUD Regular price Sale price $0.95 AUD Unit price per Each View the product page first if you are unsure.
IN-RIV-064C-066-R (5 Pcs) --- Rivet Nuts Inserts - 1/4-20 UNC -6.35mm- 9.92 - 4.19 - 6.61 IN-RIV-064C-066-R (5 Pcs) --- Rivet Nuts Inserts - 1/4-20 UNC -6.35mm- 9.92 - 4.19 - 6.61 Regular price $0.95 AUD Regular price Sale price $0.95 AUD Unit price per Out of stock! Backorder Now
Internal Thread 5/16-18 UNC (7.94mm)	Drill Hole Size 10.49 mm _{(0.413 in.)}	Grip Range 0.76 - 3.18 mm _{(0.03 in.)}	Body Diameter (D) 10.49 mm	Flange Diameter (F) 16.89 mm	L 19.050 mm
M: 1.575 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-079C-032 (5 Pcs) Rivet Nuts Inserts - 5/16-18 UNC -7.94mm- 10.49 - 0.76 - 3.18 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $2.14 AUD Regular price Sale price $2.14 AUD Unit price per Each
Internal Thread 5/16-18 UNC (7.94mm)	Drill Hole Size 10.49 mm _{(0.413 in.)}	Grip Range 0.76 - 3.18 mm _{(0.03 in.)}	Body Diameter (D) 10.49 mm
Flange Diameter (F): 16.89 mm L: 19.050 mm M: 1.575 mm Category: Inserts - Rivet Nuts - Klik
Part Number: IN-RIV-079C-032 (5 Pcs) Rivet Nuts Inserts - 5/16-18 UNC -7.94mm- 10.49 - 0.76 - 3.18 Out of Stock \| Backorder Now \| Orders can be expected around Wed, Jun 04, 2025 Regular price $2.14 AUD Regular price Sale price $2.14 AUD Unit price per Each View the product page first if you are unsure.
IN-RIV-079C-032 (5 Pcs) --- Rivet Nuts Inserts - 5/16-18 UNC -7.94mm- 10.49 - 0.76 - 3.18 IN-RIV-079C-032 (5 Pcs) --- Rivet Nuts Inserts - 5/16-18 UNC -7.94mm- 10.49 - 0.76 - 3.18 Regular price $2.14 AUD Regular price Sale price $2.14 AUD Unit price per Out of stock! Backorder Now
